BIG tires on stock wheels

I've got the stock 15x7 'ecco' wheels on my 03 tj x (I believe that is what they are called). I just picked up a set of 33x12.5 tires and a 3" BDS lift. I believe the backspacing on these wheels is 5.5.

The question is will I be able to run these tires on these wheels because of the offset. If not would a 1.25" spacer be sufficient?

I do NOT want new wheels. I like the stockers and the balloon look with my tires.

omgsideburns is offline
Sponsored Links
Advertisement

post #2 of 35 Old 07-30-2007, 02:32 PM
arbby
Registered User
2005 KJ Liberty

Join Date: May 2006
Location: SW Ontario
Posts: 908
You'll need spacers then. You will have rub with out them

|l,[___],
l---L--OlllllllO

()_) ()_)--o-)_)

Gone: 1993 YJ
arbby is offline
post #3 of 35 Old 07-30-2007, 02:34 PM
JJs99TJ
Guest

Join Date: Oct 2004
Posts: 1,498
x2 on what arbby said, plus you may need to extend your
steering stops to keep the new tires from rubbing at full
lock
JJs99TJ is offline

post #4 of 35 Old 07-30-2007, 02:59 PM Thread Starter
omgsideburns
Registered User

Join Date: Jun 2007
Posts: 191
thank you very much.

What kind of rubbing are we talking about? Spring perch contact, or just on turning? In case I don't have my spacers when I get the lift on and I feel like getting my tires on. =)

from what i've read steering stop adjustments are necessary for most big tires so no big deal there.
omgsideburns is offline
post #5 of 35 Old 07-30-2007, 03:09 PM
06WranglerX
Registered User
2006 TJ Wrangler

Join Date: Apr 2006
Location: Frelinghuysen
Posts: 1,931
Isnt that a bit to wide of a tire for 12.5 inch wide tires, isnt it advised to run atleast a 15x8 when you go above 10.5 inch tire width?

Quote:
Originally Posted by lumpster View Post
he made it clear when he said he was. He didnt ask for a photo ID of you did he.

People need to be a little more trusting, Its not like we are on a convict and rapist forum.
Quote:
Originally Posted by mrblaine View Post
Upon further reflection I've decided I've had enough of this BS and you are now on my ignore list.

06 Red Wrangler X 6 speed hard top
Ford 8.8 Detroit locked, 4 inches of lift, 33 inch BFG KM2's and some other stuff.
06WranglerX is offline
post #6 of 35 Old 07-30-2007, 03:14 PM
GaytorHater703
Registered User

Join Date: Jul 2005
Location: somewhere
Posts: 269
yea spacers....they come in sets of 2....i got 3 for sale...so if you get a set of 2...and get my 3...you will have an extra for your spare to fit on a tire carrier....same issues with back spacing on most of those....PM me if interested..i got a thread in the for sale section as well
GaytorHater703 is offline
post #7 of 35 Old 07-30-2007, 03:42 PM
jeepbro's
Registered User
2002 TJ Wrangler

Join Date: Mar 2007
Location: Wilmington
Posts: 2,770
as far as rubbing, it will be on the spring perches, and when turning, the tire will hit the frame near the swaybar and the lca,( i've got 33x12.5's) i just installed 1.5" wheels spacers, and i dont rub anywhere, and i can turn the wheel all the way with out any rubbing

2002 tj sahara 3" lift 35" km2, AtoZ rockers, 8k warn, 4.56 gears, lock-rites front and rear
jeepbro's is offline
post #8 of 35 Old 07-30-2007, 04:11 PM
KI4KWF
Member
1999 TJ Wrangler

Join Date: Dec 2006
Location: Alabama
Posts: 318
post pics! im not really sure what kind of wheels you're talking about....
KI4KWF is offline
post #9 of 35 Old 07-30-2007, 04:16 PM
TAMUJeep
Guest

Join Date: Mar 2005
Posts: 418
I have 35 x 12.5 on stock canyons with a 1.5 in spacer and don't have any rubbing...but all jeeps are different.
TAMUJeep is offline
post #10 of 35 Old 07-30-2007, 04:42 PM
KI4KWF
Member
1999 TJ Wrangler

Join Date: Dec 2006
Location: Alabama
Posts: 318
i want some canyons for my BFG 32x11.50 to skinny it up a bit
KI4KWF is offline
post #11 of 35 Old 07-30-2007, 07:13 PM Thread Starter
omgsideburns
Registered User

Join Date: Jun 2007
Posts: 191
thanks for all the words guys!
omgsideburns is offline
post #12 of 35 Old 07-30-2007, 08:08 PM
claytonandson
Web Wheeler

claytonandson's Avatar
2003 TJ Wrangler

Join Date: Apr 2006
Location: southern maryland
Posts: 1,281
i put 33/9.50/15 radial at's on my stock eccos,of course i did put a2" OME spring/shock lift on.

yellow jeep club #343
IAFF /FF's OF WASH. D.C. EMERALD SOCIETY/CHARLES COUNTY RESCUE SQUAD 51
claytonandson is offline
post #13 of 35 Old 07-30-2007, 08:19 PM
mike06X
Registered User

Join Date: Oct 2005
Location: Southington, CT
Posts: 280
i did the same thing on one of my jeeps because i paid extra for the ecco's when i bought the jeep and really felt the urge to keep them..

first, the will rub quite a bit, 10.5 wide will rub on the ecco wheels on the control arms..
second, the tires will not balloon the way you are thinking; 12.5 are wide but not balloon tires; you'll end up with a slight balloon and a overly bulged tread area that won't look good unless you run with 12 psi..

32x11.50's wouldn't be too bad, would fit the 3" lift great and if you added spacers, would give you awesome clearance.

84 CJ7 - AMC360 & T727 | 35 BFG-KM2
mike06X is offline
post #14 of 35 Old 07-30-2007, 08:57 PM Thread Starter
omgsideburns
Registered User

Join Date: Jun 2007
Posts: 191
i've already got the tires so theres no changing that. i ordered spacers so we'll just see what happens.
omgsideburns is offline
post #15 of 35 Old 07-30-2007, 09:46 PM
KennyTJ
Guest

Join Date: May 2007
Posts: 683
I've got 32x11.50 on stock 15x7's


Only rub at full steering wheel lock a little. No rubbing even disco'ed with 3" now with 4" not even close!



KennyTJ is offline
