Fork Shift Rod - JeepForum.com

LinkBack Thread Tools
post #1 of 10 Old 07-08-2006, 08:15 PM Thread Starter
hmmhoyhoy
Registered User
1995 YJ Wrangler

Join Date: Jan 2005
Location: Westminster
Posts: 965
Fork Shift Rod

I know I didnt cut enough for my SYE so I will cut it a little more, would this cause it to not be able to go into anything 4wd wise? I have been stuck in between 2H and 4H and when I try to shift back it hits and then I have to manually push it back with a screwdriver.


95 YJ
4.0 AX-15
Dana 60 f with ARB 10.25 r and open. 5.13s
37" BFG AT's

02 WJ Overland
hmmhoyhoy is offline
Sponsored Links
Advertisement

post #2 of 10 Old 07-08-2006, 09:28 PM Thread Starter
hmmhoyhoy
Registered User
1995 YJ Wrangler

Join Date: Jan 2005
Location: Westminster
Posts: 965
Bump, anyone I cant drive my Jeep until I fix this

95 YJ
4.0 AX-15
Dana 60 f with ARB 10.25 r and open. 5.13s
37" BFG AT's

02 WJ Overland
hmmhoyhoy is offline
post #3 of 10 Old 07-08-2006, 10:18 PM
balloo93
Little Red Menace

balloo93's Avatar
1993 XJ Cherokee

Join Date: Aug 2002
Location: Austin, TX
Posts: 20,820
If you disconnect the linkage and manually shift the TC into 2wd and ity lets you, it's the linkage. If it won't go into 2wd even with the linkage disco'd it's the rod.














93 Sport
Beer is proof that God loves us and wants us to be happy............Ben Franklin


Specs in Profile.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
balloo93 is offline

post #4 of 10 Old 07-08-2006, 10:24 PM Thread Starter
hmmhoyhoy
Registered User
1995 YJ Wrangler

Join Date: Jan 2005
Location: Westminster
Posts: 965
Ok great thanks Balloo, I will check it all bright and early tomorrow morning, whats the best way to disconnect the linkage?

95 YJ
4.0 AX-15
Dana 60 f with ARB 10.25 r and open. 5.13s
37" BFG AT's

02 WJ Overland
hmmhoyhoy is offline
post #5 of 10 Old 07-09-2006, 12:05 AM
Jeepin_XJ_101
Registered User
1992 YJ Wrangler

Join Date: Jan 2005
Posts: 866


Right there at the nut, the pic is sideways

"When in doubt... Floor it"
1989 XJ 4.0L I6 -
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
- NP231 - 4" RC - 33x13.50 MT Claws
*SOLD*

2005 WK 4.7L 3.5" RK, 255/75R17 on Rubi Wheels
1992 YJ 4.0L 5" ProComp on 35x12.50 Trxus MT
Jeepin_XJ_101 is offline
post #6 of 10 Old 07-09-2006, 12:17 AM Thread Starter
hmmhoyhoy
Registered User
1995 YJ Wrangler

Join Date: Jan 2005
Location: Westminster
Posts: 965
Great! Thanks Jeepin_xj_101 LOTS of help

95 YJ
4.0 AX-15
Dana 60 f with ARB 10.25 r and open. 5.13s
37" BFG AT's

02 WJ Overland
hmmhoyhoy is offline
post #7 of 10 Old 07-09-2006, 03:16 AM
conrasm
Registered User

conrasm's Avatar
2000 TJ Wrangler

Join Date: Aug 2004
Location: Pittsburgh, PA
Posts: 3,808
Some shift rods varied in length. I didn't have to trim mine when I did my SYE. I think mine protruded about 3/4" or so and if I remember correctly, the PORC SYE had a pocket about 1 1/8" deep. It protrudes the farthest in 4LO, but if you're having problems going from 2wd to 4wd HI, you may have some problems with the linkage.

Did you have a TC drop on before you did the SYE? And did you ever adjust the linkage before (like with the drop on). The bushings on the linkage can also wear and get sloppy over the years. The rebuild kit is a couple $$ from the dealer, but it's a pain to put the new bushings in.

Shawn
'00 TJ Sahara (RC 4" LA kit)
'06 Grand Cherokee Limited
'07 Ram 1500 quad cab

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
conrasm is offline
post #8 of 10 Old 07-09-2006, 08:09 PM Thread Starter
hmmhoyhoy
Registered User
1995 YJ Wrangler

Join Date: Jan 2005
Location: Westminster
Posts: 965
I didnt mess with the linkage so I dont know if its been replaced. The shaft was cut today and that seemed fine, but my shifter {4wd} is still doin the same thing and it wont go all the way back.

95 YJ
4.0 AX-15
Dana 60 f with ARB 10.25 r and open. 5.13s
37" BFG AT's

02 WJ Overland
hmmhoyhoy is offline
post #9 of 10 Old 07-09-2006, 09:44 PM
Jeepin_XJ_101
Registered User
1992 YJ Wrangler

Join Date: Jan 2005
Posts: 866
So there is probably something up with the linkage, it would shift gears and all, but the handle placement would be all off. For example 2wd=4HI, 4LO=N and there was no room to move it into 4LO. It was just dumb and before we could figure it out I had to be somewhere and had to leave the Jeep. Also the oil pump kinda fell out of position, but barely, not sure if thats gonna pose a problem or not, it didnt seem to wanna stay. What doesnt make sense is that the linkage was fine before the install, so somethin must have happened, but we are not sure what.

"When in doubt... Floor it"
1989 XJ 4.0L I6 -
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
- NP231 - 4" RC - 33x13.50 MT Claws
*SOLD*

2005 WK 4.7L 3.5" RK, 255/75R17 on Rubi Wheels
1992 YJ 4.0L 5" ProComp on 35x12.50 Trxus MT
Jeepin_XJ_101 is offline
post #10 of 10 Old 07-09-2006, 09:55 PM
Jeepin_XJ_101
Registered User
1992 YJ Wrangler

Join Date: Jan 2005
Posts: 866
Here I have a feeling this might help out your linkage problem
















































































"When in doubt... Floor it"
1989 XJ 4.0L I6 -
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
- NP231 - 4" RC - 33x13.50 MT Claws
*SOLD*

2005 WK 4.7L 3.5" RK, 255/75R17 on Rubi Wheels
1992 YJ 4.0L 5" ProComp on 35x12.50 Trxus MT
Jeepin_XJ_101 is offline
