Unread 03-22-2011, 01:25 PM   #1
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
compass clutch failure any good manuals

it would appear the clutch has gone in my 2007 compass. seems a little premature with only 67k and no towing or off road work. its the 2.0 crd.
the pedal is now like a wet fish but there was no slipping banging, grinding or any other signs it just went.
is it possible that this could infact just be the slave cylinder and or master cylinder rather than the clutch?
anyone got any experience of this and anyone no if there are any decent manuals out there for the compass as I know haynes dont do one.

Jeep want £1200 to replace the clutch, which I cant afford. I am competant with cars
any help would be appreicated

ukjeepcompass is offline   Reply With Quote Quick reply to this message
Unread 03-22-2011, 04:17 PM   #2
tjkj2002
Registered User
2002 KJ Liberty

Join Date: Dec 2009
Location: Colorado
Posts: 8,170
Being FWD based the trans will have to be dropped from underneath while the engine is supported from above(like in pic below).Big pain in the rear if doing on the ground,a lift makes it so much easier.

__________________
'02 Liberty sitting on 35" tires,HP44,RockJock60,and AtlasII t-case
tjkj2002 is offline   Reply With Quote Quick reply to this message
Unread 03-22-2011, 04:43 PM   #3
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
thanks,
On closer inspection now I have got the car home I dont think it is the clutch but more likely the slave cylinder.
is this remote or inside the clutch housing?
ukjeepcompass is offline   Reply With Quote Quick reply to this message
Unread 03-22-2011, 04:46 PM   #4
armystrong68w
Registered User
2008 MK Patriot

Join Date: Nov 2010
Location: West Boylston, MAssachusetts
Posts: 194
yeah i doubt its the clutch, it would start slipping before it gives out, you woulda had a lot of warning. plus 67k is way to low, even for someone new to driving a clutch (not saying you are, just saying in general). but yeah i have no idea what it could be, just doubt its the clutch. Gramps will help you out when he signs on!!
__________________
****Before i had a jeep I didnt know why you guys parked in snow banks and made sure to hit puddles and mud but now i understand....It really is a Jeep thing!!!!!****
armystrong68w is offline   Reply With Quote Quick reply to this message
Unread 03-22-2011, 04:52 PM   #5
tjkj2002
Registered User
2002 KJ Liberty

Join Date: Dec 2009
Location: Colorado
Posts: 8,170
Quote:
Originally Posted by ukjeepcompass View Post
thanks,
On closer inspection now I have got the car home I dont think it is the clutch but more likely the slave cylinder.
is this remote or inside the clutch housing?
If it's a internal slave cylinder then the trans must be removed,external slave the trans does not need to come out.Make sure to check the master cylinder also for leaks.
__________________
'02 Liberty sitting on 35" tires,HP44,RockJock60,and AtlasII t-case
tjkj2002 is offline   Reply With Quote Quick reply to this message
Unread 03-22-2011, 05:54 PM   #6
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
yeah I am pretty sure its not the clutch and not new to manual as most cars over here in uk are manual :P

yeah I planned to check the master cylinder and slave cylinder, didnt know there were 2 slave cylinders though, internal and external.

if its the internal one thats gone might it be worth replacing th clutch anyway if i have to take all the transmition out to do the internal cylinder?
ukjeepcompass is offline   Reply With Quote Quick reply to this message
Unread 03-23-2011, 09:07 PM   #7
Gramps
The Necessary Evil

Gramps's Avatar
2007 MK Compass

Join Date: Aug 2006
Location: Madison/Janesville, Wisconsin
Posts: 5,624
This is very abbreviated from most of the "how to's" that I post because you said that you are familiar with automotive work. If you want more info I'll be glad to post it but I'll need some time to do pictures, etc. I'm doing this down and dirty so that you can get a feel of what you're in for.

The Clutch Master mounts to the clutch pedal and is supplied with fluid from the Brake master. It consists of a piston and cylinder housing, an actuating push rod, and an interconnecting hydraulic tube.

Remove the engine cover.
Remove air cleaner assembly.
Disconnect battery negative cable. Refer
Disconnect hydraulic supply tube to clutch master cylinder. To completely drain clutch master cylinder and tubing, remove brake master cylinder cap.
Disconnect hydraulic tube and drain fluid into suitable container. Lower vehicle.
Remove instrument panel bezel.
Disconnect clutch master cylinder pushrod from clutch pedal.
Disconnect clutch master cylinder supply line from brake master cylinder reservoir, Cap off or collect reservoir fluid spillage.
Remove hydraulic tube from left rail retainer.
CAUTION: Use care when removing clutch master cylinder from engine compartment. Aggressive handling can result in a damaged hydraulic tube and improper clutch release operation upon reassembly.
Release master cylinder by rotating to disengage from pedal bracket assembly.
CAUTION: Brake fluid will damage painted surfaces. If brake fluid is spilled on any painted surfaces, wash it off immediately with water.
Remove master cylinder assembly from mounting position and carefully work hydraulic pipe from out of engine compartment.

******************************

The Clutch Slave cylinder consists of a hydraulic piston and cylinder, seal and return spring. It is fastened to the transaxle bellhousing. The slave cylinder is connected to the clutch master cylinder hydraulic pipe, which is retained to the cylinder by a pair of retainer clips, and has a bleed port to facilitate the removal of air from the system.

Remove transaxle from vehicle (Refer to TRANSMISSION/TRANSAXLE/MANUAL - REMOVAL).
Remove bolts to slave cylinder-to-clutch bellhousing bolts and remove slave cylinder from transaxle.

Install slave cylinder to transaxle using new bolts.
NOTE: Torque three CSC body screws first, then torque the fluid tube attachment.


Torque slave cylinder-to-case bolts in three steps:
2 N•m (18 in. lbs.)
5 N•m (44 in. lbs.)
8.4 N•m (74 in. lbs.)

Install transaxle - TRANSMISSION/TRANSAXLE/MANUAL - INSTALLATION.
Bleed clutch hydraulic system. - CLUTCH - STANDARD PROCEDURE.
__________________
Bob

Artificial intelligence is no substitute for natural stupidity

MK Skid Plate fasteners for sale posts 68 & 69

Also visit me at Photobucket
'06 WK Grand Cherokee Limited Quadra-Drive II, 5.7
'07 MK Compass Limited 4X4, AutoStick
Gramps is offline   Reply With Quote Quick reply to this message
Unread 03-23-2011, 09:33 PM   #8
tjkj2002
Registered User
2002 KJ Liberty

Join Date: Dec 2009
Location: Colorado
Posts: 8,170
Quote:
Originally Posted by Gramps View Post
This is very abbreviated from most of the "how to's" that I post because you said that you are familiar with automotive work. If you want more info I'll be glad to post it but I'll need some time to do pictures, etc. I'm doing this down and dirty so that you can get a feel of what you're in for.

The Clutch Master mounts to the clutch pedal and is supplied with fluid from the Brake master. It consists of a piston and cylinder housing, an actuating push rod, and an interconnecting hydraulic tube.

Remove the engine cover.
Remove air cleaner assembly.
Disconnect battery negative cable. Refer
Disconnect hydraulic supply tube to clutch master cylinder. To completely drain clutch master cylinder and tubing, remove brake master cylinder cap.
Disconnect hydraulic tube and drain fluid into suitable container. Lower vehicle.
Remove instrument panel bezel.
Disconnect clutch master cylinder pushrod from clutch pedal.
Disconnect clutch master cylinder supply line from brake master cylinder reservoir, Cap off or collect reservoir fluid spillage.
Remove hydraulic tube from left rail retainer.
CAUTION: Use care when removing clutch master cylinder from engine compartment. Aggressive handling can result in a damaged hydraulic tube and improper clutch release operation upon reassembly.
Release master cylinder by rotating to disengage from pedal bracket assembly.
CAUTION: Brake fluid will damage painted surfaces. If brake fluid is spilled on any painted surfaces, wash it off immediately with water.
Remove master cylinder assembly from mounting position and carefully work hydraulic pipe from out of engine compartment.

******************************

The Clutch Slave cylinder consists of a hydraulic piston and cylinder, seal and return spring. It is fastened to the transaxle bellhousing. The slave cylinder is connected to the clutch master cylinder hydraulic pipe, which is retained to the cylinder by a pair of retainer clips, and has a bleed port to facilitate the removal of air from the system.

Remove transaxle from vehicle (Refer to TRANSMISSION/TRANSAXLE/MANUAL - REMOVAL).
Remove bolts to slave cylinder-to-clutch bellhousing bolts and remove slave cylinder from transaxle.

Install slave cylinder to transaxle using new bolts.
NOTE: Torque three CSC body screws first, then torque the fluid tube attachment.


Torque slave cylinder-to-case bolts in three steps:
2 N•m (18 in. lbs.)
5 N•m (44 in. lbs.)
8.4 N•m (74 in. lbs.)

Install transaxle - TRANSMISSION/TRANSAXLE/MANUAL - INSTALLATION.
Bleed clutch hydraulic system. - CLUTCH - STANDARD PROCEDURE.
So they do use a internal slave cylinder,that sucks.
__________________
'02 Liberty sitting on 35" tires,HP44,RockJock60,and AtlasII t-case
tjkj2002 is offline   Reply With Quote Quick reply to this message
Unread 03-23-2011, 09:46 PM   #9
Gramps
The Necessary Evil

Gramps's Avatar
2007 MK Compass

Join Date: Aug 2006
Location: Madison/Janesville, Wisconsin
Posts: 5,624
Ya, I had posted that info a few years back but never dis a write up. They just wasnted to know where it was and didn't want to get into working on it themselves. Pulling the dash for the little clutch master "piston and cylinder" sucks too.
__________________
Bob

Artificial intelligence is no substitute for natural stupidity

MK Skid Plate fasteners for sale posts 68 & 69

Also visit me at Photobucket
'06 WK Grand Cherokee Limited Quadra-Drive II, 5.7
'07 MK Compass Limited 4X4, AutoStick
Gramps is offline   Reply With Quote Quick reply to this message
Unread 03-24-2011, 01:59 PM   #10
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
top work gramps.
it sounds worse than I imagined but hey ho on we go. might as well put a new clutch plate in if i end up going in for the slave.
I am pretty sure I follow it all but keep an eye out for me shouting HELP!!

I plan on starting it on Tuesday I think. and will hopefully be running by Thurday

when you say pulling the dash do you mean the dashboard has to come out?
ukjeepcompass is offline   Reply With Quote Quick reply to this message
Unread 03-24-2011, 02:57 PM   #11
Gramps
The Necessary Evil

Gramps's Avatar
2007 MK Compass

Join Date: Aug 2006
Location: Madison/Janesville, Wisconsin
Posts: 5,624
Quote:
Originally Posted by ukjeepcompass View Post
when you say pulling the dash do you mean the dashboard has to come out?
No, they would call that the "Instrument Cluster". They normally have a link in the Service manual if there are other areas that need to be removed but this doesn't. If there is not some kind of "bezel" that is obvious when you get the previous parts removed then they may be talking about the "steering column opening cover", under the dash, that by removing it would allow access to the clutch rod. It can simply be removed with a trim stick. I want to just add that if we were getting deep into the cluster and electrical system there would be a CAUTION for disconnecting the air bag sensor, and they don't. I think we're making more of this than we need to, I hope.

Here they have a slightly different term on the installation instructions.

1. Install clutch master cylinder (1).
2. Insert tube into master cylinder port and install retaining clip (5).
3. Connect clutch master cylinder supply hose (2) to brake master cylinder reservoir (1).
4. Verify that brake master cylinder reservoir is full and cap is off.
5. Position clutch master cylinder body vertically, with pushrod pointing down, for about ten seconds to purge air trapped from end of cylinder.
6. Install clutch master cylinder body to dash panel and 1/4 turn to secure.
7. Connect clutch master cylinder rod to clutch pedal pin. An audible “click” should be heard.
8. Install lower instrument panel bezel.
9. Connect battery negative cable.
10. Install air cleaner assembly (1).
11. Verify that brake master cylinder reservoir is full. Top off with DOT 3 brake fluid if necessary.
12. Bleed clutch system (More info on this is available too, if needed).
13. Actuate clutch pedal a minimum of fifteen times to allow any air ingested into the system to vent to the master cylinder reservoir. If residual air becomes trapped in the system, it is necessary to bleed the clutch hydraulic system.
14. Verify proper clutch release system operation.
assembly.jpg   engine-compartment.jpg
__________________
Bob

Artificial intelligence is no substitute for natural stupidity

MK Skid Plate fasteners for sale posts 68 & 69

Also visit me at Photobucket
'06 WK Grand Cherokee Limited Quadra-Drive II, 5.7
'07 MK Compass Limited 4X4, AutoStick
Gramps is offline   Reply With Quote Quick reply to this message
Unread 03-24-2011, 05:06 PM   #12
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
magic, cheers

ill keep everyone posted anyways, and ill take my camera for a few piccies along the way
ukjeepcompass is offline   Reply With Quote Quick reply to this message
Unread 03-24-2011, 05:37 PM   #13
Gramps
The Necessary Evil

Gramps's Avatar
2007 MK Compass

Join Date: Aug 2006
Location: Madison/Janesville, Wisconsin
Posts: 5,624
I hope that it goes well for you!
__________________
Bob

Artificial intelligence is no substitute for natural stupidity

MK Skid Plate fasteners for sale posts 68 & 69

Also visit me at Photobucket
'06 WK Grand Cherokee Limited Quadra-Drive II, 5.7
'07 MK Compass Limited 4X4, AutoStick
Gramps is offline   Reply With Quote Quick reply to this message
Unread 03-24-2011, 11:02 PM   #14
Rob K
Registered User
1995 XJ Cherokee

Join Date: Sep 2007
Location: River Falls, Wisconsin
Posts: 1,222
I'll be following along here. I may be getting a Patriot in the future and I'm interested to know how the clutch is done on one of these. I may be doing this repair myself someday. Some pics and descriptions would be good if you have the time.
Rob K is offline   Reply With Quote Quick reply to this message
Unread 03-26-2011, 07:45 AM   #15
ukjeepcompass
Registered User

Join Date: Feb 2011
Location: sheffield, uk
Posts: 20
hey,
I ma getting confused now,
after taking off all the plastics and the air box etc so I can see what is going on I have been pumping the clutch whilst my dad looks for movement and leaks. we have been unable to locate any leaks but in the pumping the clutch has gone back to normal and is working.
this has styumped me a bit as there is obviously a problem for it to have all gone wrong in the first place. we are thinking along the lines of air in the system but how its got there? there could be a split in a pipe but i cant see one. Am i right in thinking that the clutch runs off of the brake fluid resevoir? and is there a separate bleed or is it just like usual that you remove the resevoir lid and pump to push the air out of the clutch?

any suggestions or anyone experience similar things any feedback would be appreciated.

cheers
ukjeepcompass is offline   Reply With Quote Quick reply to this message
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the JeepForum.com forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid e-mail address for yourself.
Note: All free e-mails have been banned due to mis-use. (Yahoo, Gmail, Hotmail, etc.)
Don't have a non-free e-mail address? Click here for a solution: Manual Account Creation
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.


Thread Tools


Suggested Threads





Jeep, Wrangler, Cherokee, Grand Cherokee, and other models are copyrighted and trademarked to Jeep/Chrysler Corporation. JeepForum.com is not in any way associated with Jeep or the Chrysler Corp.
