post #2296 of 3992 Old 08-20-2012, 07:08 PM
Wonk
Registered User
2012 JK Wrangler

Join Date: Apr 2006
Location: Southern Indiana
Posts: 150
Quote:
Originally Posted by jvandy50 View Post
^^this. And 3 grown men at least. It may depend on the tires but the MTR/K just did not want to stretch over that outer bead. We had to use fender washers to hold our place on the other side or about a 1/4 of the tire would just pop up on the other side. Used a couple molding tools and a wonder bar to bring lip over, and then a dead blow hammer to beat it the rest of the way over.

All the videos I've watched on the Internet DID NOT look that hard at all. Granted this was our first time doin it, but it just wasn't as easy as I thought. I knew it'd be tedious, and that was the easy part, but we are all sore after doin 5 lol
HUH??? What are you talking about? You didn't bolt the beadlock ring on before putting the tire on the wheel did you? I don't understand.

Wonk is offline
Sponsored Links
Advertisement

post #2297 of 3992 Old 08-20-2012, 07:17 PM
AppSt59Dave
Registered User
2012 WK

Join Date: Sep 2010
Location: Mooresville
Posts: 811
Quote:
Originally Posted by Wonk

HUH??? What are you talking about? You didn't bolt the beadlock ring on before putting the tire on the wheel did you? I don't understand.
That's funny as sheet. I just spit out my banana pudding!

'78 CJ-5 Loden Green, in the barn
'12 WK2 Black Forest Green Hemi
AppSt59Dave is offline
post #2298 of 3992 Old 08-20-2012, 07:23 PM
Wonk
Registered User
2012 JK Wrangler

Join Date: Apr 2006
Location: Southern Indiana
Posts: 150
Quote:
Originally Posted by AppSt59Dave View Post
That's funny as sheet. I just spit out my banana pudding!
Not trying to be funny. I've actually seen a Jeep dealership "install" a set of beadlocks on a new Jeep and they put the outer tire bead over the lip that the beadlock ring bolts to then bolted the beadlock ring on. I still don't know how they held air.
Wonk is offline
post #2299 of 3992 Old 08-20-2012, 07:28 PM
jvandy50
Registered User
2010 JK Wrangler

Join Date: Apr 2010
Location: AR
Posts: 78
probably bad terminology on my part. See the tire by the upper right corner of rim, it wouldn't go over the wheel without another part popping up. Not even with a 230# guy standing on the area that was already seated, it'd still pop up


jvandy50 is offline
post #2300 of 3992 Old 08-20-2012, 07:34 PM
AppSt59Dave
Registered User
2012 WK

Join Date: Sep 2010
Location: Mooresville
Posts: 811
Quote:
Originally Posted by jvandy50
probably bad terminology on my part. See the tire by the upper right corner of rim, it wouldn't go over the wheel without another part popping up. Not even with a 230# guy standing on the area that was already seated, it'd still pop up
Width on that MTR? 13.50? I'll be mounting
Either a 35x12.50 Trail Grappler or a 36x14(I think) Irok Radial. Either way, lots of sunshine and tire lube!

'78 CJ-5 Loden Green, in the barn
'12 WK2 Black Forest Green Hemi
AppSt59Dave is offline
post #2301 of 3992 Old 08-20-2012, 07:50 PM
Wonk
Registered User
2012 JK Wrangler

Join Date: Apr 2006
Location: Southern Indiana
Posts: 150
Quote:
Originally Posted by AppSt59Dave View Post
Width on that MTR? 13.50? I'll be mounting
Either a 35x12.50 Trail Grappler or a 36x14(I think) Irok Radial. Either way, lots of sunshine and tire lube!
Just to clarify, the tire doesn't go OVER the part that has the bolt holes in it. It rests on TOP of this ring and is squeezed between the rim and beadlock ring. Shouldn't need any tire lube. With the tire in the position it is in the above pic, lay the ring on the wheel and use 4-6 extra long bolts evenly spaced around the ring to start the ring down evenly on the tire/wheel. Once everything is centered up, start putting in the regular bolts and tighten them in a criss-cross pattern a little at a time (neversieze all the bolts) and replace the long bolts with the supplied regular bolts. Keep tightening in the criss-cross pattern a little at a time until they are all evenly torqued to the recommended torque setting. Repeat 3-4 more times.
Wonk is offline
post #2302 of 3992 Old 08-20-2012, 07:53 PM
jvandy50
Registered User
2010 JK Wrangler

Join Date: Apr 2010
Location: AR
Posts: 78
Quote:
Originally Posted by AppSt59Dave View Post
Width on that MTR? 13.50? I'll be mounting
Either a 35x12.50 Trail Grappler or a 36x14(I think) Irok Radial. Either way, lots of sunshine and tire lube!
12.50. We didn't have much heat here saturday so i put em in the powdercoating oven at 140 pretty much all day. used some soapy water too(mostly soap). i had read these tires were not fun to mount in multiple threads on forums, and that pretty much turned out to be true.. for us anyway. and no i didn't bolt up the ring and then try it. hope you have an easier time than we did!
jvandy50 is offline
post #2303 of 3992 Old 08-20-2012, 08:28 PM
jvandy50
Registered User
2010 JK Wrangler

Join Date: Apr 2010
Location: AR
Posts: 78
Quote:
Originally Posted by Wonk View Post
Just to clarify, the tire doesn't go OVER the part that has the bolt holes in it. It rests on TOP of this ring and is squeezed between the rim and beadlock ring. Shouldn't need any tire lube. With the tire in the position it is in the above pic, lay the ring on the wheel and use 4-6 extra long bolts evenly spaced around the ring to start the ring down evenly on the tire/wheel. Once everything is centered up, start putting in the regular bolts and tighten them in a criss-cross pattern a little at a time (neversieze all the bolts) and replace the long bolts with the supplied regular bolts. Keep tightening in the criss-cross pattern a little at a time until they are all evenly torqued to the recommended torque setting. Repeat 3-4 more times.
this isn't how mine worked. we needed lube to get the tire on, and the longer bolt idea didn't work for us. it didn't "rest" on anything, it had to be persuaded like crazy and then put the ring on. and by the time we had the inner tire over the lip, the standard bolts reached, just barely, but they did.

OP, what wheel did you order? i'm guessing some are designed a little differently
jvandy50 is offline
post #2304 of 3992 Old 08-21-2012, 11:45 AM
jvandy50
Registered User
2010 JK Wrangler

Join Date: Apr 2010
Location: AR
Posts: 78
Quote:
Originally Posted by Wonk View Post
Just to clarify, the tire doesn't go OVER the part that has the bolt holes in it. It rests on TOP of this ring and is squeezed between the rim and beadlock ring. Shouldn't need any tire lube. With the tire in the position it is in the above pic, lay the ring on the wheel and use 4-6 extra long bolts evenly spaced around the ring to start the ring down evenly on the tire/wheel. Once everything is centered up, start putting in the regular bolts and tighten them in a criss-cross pattern a little at a time (neversieze all the bolts) and replace the long bolts with the supplied regular bolts. Keep tightening in the criss-cross pattern a little at a time until they are all evenly torqued to the recommended torque setting. Repeat 3-4 more times.
this isn't how mine worked. we needed lube to get the tire on, and the longer bolt idea didn't work for us. it didn't "rest" on anything, it had to be persuaded like crazy and then put the ring on. and by the time we had the inner tire over the lip, the standard bolts reached, just barely, but they did.

AppSt59Dave, what wheel did you order? i'm guessing some are designed a little differently
jvandy50 is offline
post #2305 of 3992 Old 08-21-2012, 04:51 PM
AppSt59Dave
Registered User
2012 WK

Join Date: Sep 2010
Location: Mooresville
Posts: 811
Quote:
Originally Posted by jvandy50

this isn't how mine worked. we needed lube to get the tire on, and the longer bolt idea didn't work for us. it didn't "rest" on anything, it had to be persuaded like crazy and then put the ring on. and by the time we had the inner tire over the lip, the standard bolts reached, just barely, but they did.

AppSt59Dave, what wheel did you order? i'm guessing some are designed a little differently
ATX Slabs. Im doing an article on it for my company's website and fb page. Should be a fun learning experience

'78 CJ-5 Loden Green, in the barn
'12 WK2 Black Forest Green Hemi
AppSt59Dave is offline
post #2306 of 3992 Old 08-21-2012, 04:58 PM
Xet2ss615
Registered User
2012 JK Wrangler

Join Date: Aug 2012
Location: Chesapeake
Posts: 4
AEV 3.5" lift
17" AEV pintlers, argent color
35" Goodyears
2012 Sahara JKU
Wife hates it now, too tall. Rock sliders power step sliders in the mail!
Attached Thumbnails
2012-07-27_17-04-07_152.jpg   photo-1.jpg   photo-2.jpg
Xet2ss615 is offline
post #2307 of 3992 Old 08-21-2012, 05:01 PM
Xet2ss615
Registered User
2012 JK Wrangler

Join Date: Aug 2012
Location: Chesapeake
Posts: 4
opps
Xet2ss615 is offline
post #2308 of 3992 Old 08-21-2012, 05:03 PM
Xet2ss615
Registered User
2012 JK Wrangler

Join Date: Aug 2012
Location: Chesapeake
Posts: 4
opps
not sure why upside down!
Xet2ss615 is offline
post #2309 of 3992 Old 08-21-2012, 06:00 PM
jvandy50
Registered User
2010 JK Wrangler

Join Date: Apr 2010
Location: AR
Posts: 78
Quote:
Originally Posted by AppSt59Dave

ATX Slabs. Im doing an article on it for my company's website and fb page. Should be a fun learning experience
So pretty much same wheel as me with different ring. Those were back ordered when I got wheels. Love em. If you have any question during install feel free to holler at me. I can give ya the links I used to help us out. I don't think it'll be as difficult as long as you use a tire that isn't an MTR/K. That seems to be the common denominator in the other 2 folks I found that had a PITA time mounting them. Good luck and post some pics when done!
jvandy50 is offline
post #2310 of 3992 Old 08-21-2012, 06:08 PM
Papawhiskey
Registered User
2011 JK Wrangler

Join Date: Aug 2011
Location: Escondido
Posts: 81
Doors off
Papawhiskey is offline
