Trunk for 06 TJ Unlimited (LJ)

Someone has probably asked this before, Can someone/anyone tell me or show me how to build a trunk for my 06 TJ Unlimited (with or without back seat). I am in the military and have to carry some gear with me to work sometimes. I love having the top off, with the gear and the top off I would be asking someone to walk away with my stuff. So if any one can guide me in the right direction?

chad_33us is offline   Reply With Quote
Unread 02-09-2009, 06:37 PM   #2
ian0341fo
Registered User
2006 LJ Wrangler

Join Date: Oct 2007
Location: San Clemente, CA
Posts: 108
Tuffy Products. http://www.quadratec.com/products/24252_101_07.htm I have one of these in my LJ and works great. I'm a Marine, so I'm always hauling gear in there, just like you. Its big enough to fit a day pack and a broken down M-16, not that I'd know.
__________________
2006 LJ Rubicon
ian0341fo is offline   Reply With Quote
Unread 07-28-2009, 03:13 AM   #3
chad_33us
Registered User
2006 LJ Wrangler

Join Date: Mar 2007
Location: Oahu, Hiawaii
Posts: 56
Need measurements

Could anyone get me the measurements for building a trunk in a 06 Rubicon Unlimited? I am currently deployed to Iraq and have some down time. I am going to build here and bring home (have the ability to do so). Would like to build one to keep the rear seat in so the family can enjoy the off roading with me.
THANKS
chad_33us is offline   Reply With Quote
Unread 07-28-2009, 07:11 AM   #4
grogie
M-F: Cell Block #4533

grogie's Avatar
2006 TJ Wrangler

Join Date: Nov 2005
Location: Indy
Posts: 7,241
Chad, first, thanks for your service!

Second, I don't have one but it is on my list to build as well. If you go to the link below, Tuffy has two boxes, and they have the sizes for each if you click on them.

http://www.tuffyproducts.com/s-55-2004-2006.aspx
__________________

Red Jeep Club #345
2006 TJ Sport
2004 KJ Limited
2013 Off-Road Trailer

grogie is offline   Reply With Quote
Unread 07-28-2009, 07:24 AM   #5
Unlimited04
This post/info=my opinion

Unlimited04's Avatar
2004 LJ Wrangler

Join Date: Dec 2005
Location: Colorado
Posts: 23,227
make your own, lots cheaper.
Unlimited04 is offline   Reply With Quote
Unread 07-28-2009, 07:38 AM   #6
DBLJ
Web Wheeler

DBLJ's Avatar
2005 LJ Wrangler

Join Date: Apr 2007
Location: Braintree, Massachusetts
Posts: 2,907
I just cut a piece of plywood to fit it. I need to carpet it and put a piece that runs to the floor and secure it down. You won't be able to remove it due to how tight it is
DBLJ is offline   Reply With Quote
Unread 07-28-2009, 07:55 AM   #7
Scotch740
Registered User
2005 LJ Wrangler

Join Date: Apr 2004
Location: Charlottesville VA
Posts: 2,327
Heres what I did. I am very happy with it and it was cheap.
http://www.jeepforum.com/forum/f9/contico-tuff-bin-installed-unlimited-w-rear-seat-590637/

Scotch740 is offline   Reply With Quote
Unread 07-28-2009, 08:49 PM   #8
RubiOR
Registered User
2006 LJ Wrangler

Join Date: Jul 2008
Location: Atlanta
Posts: 190
Quote:
Originally Posted by chad_33us View Post
Someone has probably asked this before, Can someone/anyone tell me or show me how to build a trunk for my 06 TJ Unlimited (with or without back seat). I am in the military and have to carry some gear with me to work sometimes. I love having the top off, with the gear and the top off I would be asking someone to walk away with my stuff. So if any one can guide me in the right direction?
Hey Chad. That's the 2nd thing I did to my LJ when I got it last year. Gotta have a place to put stuff! http://www.jeepforum.com/forum/showp...61&postcount=4

My dimensions are 22" front to back, 12" high and 35" left to right. One sheet of diamond plate with three bends and a bit of welding. The bottom edges of the sides have angle iron welded in to give me a lip for screwing / bolting it to the floor. That could have been another pair of bends I suppose.

If you don't make right angles you could make the bottom more than 22 since the rear seat slopes back a bit. I'm not quite sure of that distance but if I pull the box out anytime soon I'll get a measurement for you. Since mine *is* right angles I just stuff random things down between the box & back of the seat.

If you pull the carpet out you'll need to either put spacers under the sides or make the sides longer than the front. 1/2" should just about do it. I'll be doing this soon since I have a tendency to get caught in the rain now & then. At the same I'm going to replace the sheet metal screws with nutserts / rivnuts which should be a bit more stable.
__________________
'06 Solar Yellow Rubicon Unlimited -- The Big Yellow Brick
Their huge yellow spaceships hung in the air in exactly the same way that bricks don't. -- Douglas Adams, Hitch Hiker's Guide to the Galaxy
RubiOR is offline   Reply With Quote
Unread 07-28-2009, 09:03 PM   #9
DINOCAVE
formerly CPT Jeep

DINOCAVE's Avatar
2005 LJ Wrangler

Join Date: Feb 2006
Location: St Robert, MO
Posts: 1,315
I've put a lot of thought into this, even though I don't have a LJ yet. I don't like the wood designs because they are too heavy and not that nice, in my opinion. I don't like the Tuffy boxes because I think you sacrifice too much usable space by trying to fit everything into a drawer.

I think the best design is something based off the Olympic Trunk. http://www.quadratec.com/products/14147_1200_07.htm

I'd like to see someone build this product, but for a LJ. The top needs to have a hinged section to allow larger items to fit with the trunk lid lifted. It would also be nice if the front/back section was hinged to allow long items to be carryed flat if the back seat was folded forward. While I'm dreaming, it should be aluminum to save weight since this would take a pretty significant bit of metal for this.

I have designed and redesigned this trunk in my head several times when I dream of outfitting "NextJeep". Once I buy my LJ, I will try to build it myself using cardboard templates first and then aluminum. If you can wait 2-3 years, you can see how mine turns out.
DINOCAVE is offline   Reply With Quote
Unread 07-28-2009, 11:01 PM   #10
DaleII
Registered User
2005 LJ Wrangler

Join Date: Jan 2009
Location: Riverside/Apple Valley, California
Posts: 1,507
I built something myself like that Olympic trunk. I essentially took 1" tubing and make to runner that go across the back and behind the rear seat and bolt on the sides. I put three cross bars across them, and cut and rivited diamond plate to the top of it. Then to make sure the seat doesn't fold forward I put an I-Bolt thought the latch and secured it with a lock to the frame. I can take some picture tomorrow if you'd like?
DaleII is offline   Reply With Quote
Unread 07-28-2009, 11:03 PM   #11
DaleII
Registered User
2005 LJ Wrangler

Join Date: Jan 2009
Location: Riverside/Apple Valley, California
Posts: 1,507
Quote:
I'd like to see someone build this product, but for a LJ. The top needs to have a hinged section to allow larger items to fit with the trunk lid lifted. It would also be nice if the front/back section was hinged to allow long items to be carryed flat if the back seat was folded forward. While I'm dreaming, it should be aluminum to save weight since this would take a pretty significant bit of metal for this.
It should be fairly easy to build this from something like I have. I didn't think of building it like that. I was more concerned about just getting it covered.
DaleII is offline   Reply With Quote
Unread 07-29-2009, 06:26 PM   #12
DINOCAVE
formerly CPT Jeep

DINOCAVE's Avatar
2005 LJ Wrangler

Join Date: Feb 2006
Location: St Robert, MO
Posts: 1,315
Quote:
Originally Posted by DaleII View Post
I built something myself like that Olympic trunk. I essentially took 1" tubing and make to runner that go across the back and behind the rear seat and bolt on the sides. I put three cross bars across them, and cut and rivited diamond plate to the top of it. Then to make sure the seat doesn't fold forward I put an I-Bolt thought the latch and secured it with a lock to the frame. I can take some picture tomorrow if you'd like?
I'd like to see some pictures of what you have. Outside and looking in with the back door opened.
DINOCAVE is offline   Reply With Quote
Unread 07-30-2009, 01:31 AM   #13
DaleII
Registered User
2005 LJ Wrangler

Join Date: Jan 2009
Location: Riverside/Apple Valley, California
Posts: 1,507
I'll try and get the pics tomorrow when I take my top off. Need sunlight, and it's 12:31 for me right now.
DaleII is offline   Reply With Quote
Unread 07-30-2009, 06:07 PM   #14
gus54
Registered User
1999 TJ Wrangler

Join Date: Sep 2008
Location: NE Ohio
Posts: 394
Here's a link to my trunk build. I've since added 3/8" aluminum angle to the edges for looks, strength, and durability and got rid of the weather stripping on the tailgate side and just carpeted that edge too. No recent pics - sorry.

http://www.jeepforum.com/forum/showt...nk#post7044747
gus54 is offline   Reply With Quote
Unread 07-31-2009, 10:49 AM   #15
chad_33us
Registered User
2006 LJ Wrangler

Join Date: Mar 2007
Location: Oahu, Hiawaii
Posts: 56
next question

Thanks guys
All the designs look great and have given me some great ideas. Keep'm going. Now the question is what material do you all think is better.
1. WOOD
-Is it to heavy?
-Not as weather resistant?

2. METAL
- Will it bang around?
- More secure?

Let me know what you all think
chad_33us is offline   Reply With Quote
