Name: Lance T Kenyon, Peoria, AZ
Mods: 01 TJ
Engine: 4.0 w 62mm throttle body and spacer, CAI.
Transmission: Stock NV3550.
Transfer case: Swapped in Rubi NV241OR.
Drive shafts: F/R Phx Rack and Axle CV driveshafts.
Suspension: Rock Krawler custom long arm stretch system to 111” WB(10” rear stretch, 7.5” front stretch), 3 link front w custom Lost Offroad Fab track bar, 4 link rear.
Springs/shocks: FOA 16” coilovers front, Procomp 3” coils rear with Procomp 3000s(5” of suspension lift over stock, 1" body lift).
Rear axle: Jeep J20 LP D60 rear w 35 spline Teraflex 4140H chromos, Yukon full spool, Yukon 5.86 R&P, Alloy USA cover, RK cradle, Genright LCA mounts, Teraflex disc brakes.
Front axle: 01 Dodge LP D60 front w RCV shafts(35 spline 4140H chromo 1 pc inners, 33 spline 300M outers), PSC dbl ram full hydro steering, Lost Offroad Fab full trussing, Spartan locker, Yukon 5.86 R&P, stock Dodge disc brakes, Riddler diff cover.
Rims/tires: 17x8.5 Walker Evans beadlocks with 39-13.50-17 BFG Red Label Krawlers.
Other mods: Full custom cage, Warn sliders, BS Sand suspension seats, Crow 5 point harnesses, Warn XD9000i winch and Warn winch plate, KC 150w Daylighter headlights, rock lights, killer trail tunes, custom sheet metal work by AZ rocks.
Story: I bought this Jeep new off the showroom floor in 2001 as a daily driver for my wife. After 3 years of occasional hunting out of it, I went on my first real trail run and was hooked. It has taken 6+ years to bring my rig to its current state. I thank my loving wife and 2 daughters for putting up with the late hours and tons of money put into my big weekend toy.
Name: John Hendrix
1997 Jeep Wrangler Sport TJ (104 inch WB)
4.0 L 32rh 3 Speed Auto Deep pan Currie SYE and DS
JK Rubicon Rear D44, UCF diff cover, TNT truss
JK Rubicon HP D44 Riddler Diff cover, TNT truss and custom Sleeves
37/12.50/17 BFG Krawlers
ROKMEN dual JJ control arms uppers and lowers
2.5 RC springs
stock rear springs
Currie Bump stops
RCI Fuel Cell w/ Jimmys 4x4 cell Mount
ROKMEN Steering box Skid
Undercover Fabworks Ultra High Clearance Skid
Custom 1 Ton HD steering and track bars ¾ inch Spidertrax Heims and 1.5 inch thick wall DOM
Northridge4x4 Stainless steel brake lines Front and rear
Undercover Fabworks Engine Skid 97-02 Prototype
ROKMEN HiLine fenders with custom trimmed hood
ROKMEN Mercenary Rocker armor w/tubes
SAVVY OFFROAD Corner armor COMP cut ,Tail gate skin, and Valance
ROKMEN hood pins
Mile Marker winch (temporarily out of order)
ROKMEN Front L-TJ winch bumper
ROKMEN rear cross member bumper
12 inch travel Bilstiens
Jeep is stretched to LJ unlimited WB.
Plans in the works
AW4 W/deep pan, shift kit, Hydro assist, Beef up the JK axles more, and a Cage
Story: I have done all the work by myself. I started out in February of 2010 with just a simple LCOG build. Highline fenders, 2.5 in lift, Tummy Tuck, and 35 in MTRs. I completed the build in May. I was hit by a driver on a cell phone on June 1st, resulting in a flop on my passenger side. After a few weeks of fighting with the INS Company I was paid for the damages to my Jeep, funding some of the second part of my build. I sold off some of my like new parts also. Recoil sent me a link for a set of new JK Rubicon axles for a good deal. I ordered a pair of TNT trusses and some other Rokmen goodies. I spent 2 months with 100 plus temps stretching my frame, cleaning and welding the TNT trusses on the new JK axles. I also built from scratch 1 ton steering with spider trax hiems. I finished the Jeep a week before my second trip to Badlands, with some of my JF brothers and IndyORV guys. I am very happy with my Jeep. I drive it everyday to work 60 miles round trip. I get a ton of looks and thumbs up.
My build thread
Name: Craig Anderson
* 4" pro Comp Stage 2 SA lift
* 35x12.50 Cooper STT
* 15x10 Aluminum AWC rockcrusher wheels
* Currie HD Steering System
* OME Steering Stabalizer
* JKS Adj Rear end links
* 4.10 gears
* Rubicon E-lockers
* Warn bumper front and rear w/ Tire carrier
* Golden Eagle CB antenna w/ Cobra 19dx CB/PA system
* 2 KC 100watt daylighters w/ KC windshield brackets
* JKS Racing shock adapter
* JKS Racing Shock front Bar Pin Eliminator
* 2.0x10" Fox smoothbody reservoir shocks with 2 Bilstein 5100 long travel shocks in the rear
* Flowmaster 40 exhaust and tubing
* Cut Fenders front and rear
* C.R.E.S Net top
* Bestop Bikini Top
* Rubicon Sliders
* Kilby Steering Box Skid
This is my very first Jeep. I love everything about it. For a broke college student, most everything on this rubi has been invilved in a trade for an upgrade (for example: 33's trade for 35's). I'm always thinking of how to make it look the best, for the cheapest, and most fuctional way possible. It has just started, but the rubi's life has a long path ahead of it and isn't even close to being finished yet. -Craig
Front, Dana 60/44 hybrid, Rear 60
I recently finished my 2001 TJ's build. This is the first Jeep I've owned. Over the past 3 years, I've learned a ton about Jeeps, and developed some new skills. After wheeling it hard in its stock form, I desired more. I wanted a daily driver that killed it on the rocks. I knew this would take a ton of research, and a ton of work. I searched and searched, and finally, after a few years, I found some axles that I thought would be a great swap. The front, a 60/44 hybrid, the rear, a 60. These axles inspired the complete build. I just needed a place to do the build. I had recently picked up a welder, and freshened up some old skills. As it turns out, I had a friend of a friend who had a garage. He was going to be out of town for 3 weeks, and if I could get it done in that amount of time, the garage was all mine. After building the Jeep in the parking lot of my condo complex. I figured this garage was a great opportunity! I quickly dove in head first. I'm extremely happy with the latest modifications. It was a ton of work and a ton of fun...of course it is never done!
Name: Steve Hogan
Username: Blackwidow TJ
Chromoly USA alloys front shafts
Superior chromoly rears
RE long arms
Homebrew highline with Poison Spyder tube fenders
Homemade rock sliders
Home made snorkle
Home made radiator skid
Over the knuckle 1.5x .250 wall dom steering W/ Chevy Rod Ends
Fishmouth Fabworks Grille Hoop
Ruff stuff diff covers
36x12.5x15 TSL XS's
CJ7 Front Signals and Tailgate
Full Poison Spyder Cage
"H8 YOTAS" License Plates
Bought it brand new in 2004, rolled it before the first payment, haven't looked back since, It's a daily driver built for wheeling.....the best has yet to come.
Build thread can be seen here http://www.jeepforum.com/forum/f9/my...ining-1055667/
One tons and LJ links getting ready to go in!
