oil pressure sending unit question

I decided to try getting my oil pressure gauge going. I'm looking at the sending unit, and I see a 3 prong connector. I can't find the matching connector or wiring that might go to it. There is one to to top. I get nothing at the gauge, no movement at all.


wsmutch is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 11:29 AM   #2
WindKnot
Web Wheeler

WindKnot's Avatar
1977 CJ7

Join Date: Mar 2011
Location: Kaibab Plateau, Northern Arizona
Posts: 3,100
Look at my picture. The sender is the one on the left. There should be only one wire attached. For my year it is purple. On the right side is another sender dependent on oil pressure. For me it was an aftermarket electric fuel pump that will shut off the pump when the engine is stopped even though the ignition is still on. (Like for example if I ran into a tree or something.)

You have something similar but it's from the factory. Your Jeep is newer than mine. It maybe was a hookup for a computer or something emissions related, I don't know. But for the oil pressure gauge, you want to hook up to the sensor that looks like mine.

__________________
I'd rather be lost on the trails than found at home!

Phoenix Rising- A Flame Off Restoration? http://www.jeepforum.com/forum/f8/ph...ation-1807257/
WindKnot is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 11:30 AM   #3
gosupes
Registered User
1986 CJ7

Join Date: Jun 2004
Location: Monroe, WA
Posts: 1,541
That's a pressure switch, used for idiot lights, manifold heaters among other things. Three terminals, likely common, normally open and normally closed. Your pressure sensor is the round can right above the switch behind that bundle of wires. I think the sensor just uses a wiper arm across a resistive element. You can try using an ohmmeter from the terminal to a good ground and see if it changes with pressure changes. Or just say the hell with it and plumb in a mechanical gauge.
__________________
1986 CJ7, 4.2 w/4.0 head, TFI-HEI hybrid ignition, Clifford manifold w/Holley 390 w/cold air intake, OBA, 4.5" lift, Woody CV shaft and Tattons in front, 4.10 gears - lunchbox in front, Truetrac in the back, twin-sticked, blower upgrade for running topless, trying to keep it simple.

It's just a Jeep, and if you don't wheel it once in a while, it's not even that.
gosupes is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 11:34 AM   #4
LumpyGrits
Registered User
1985 CJ7

Join Date: Jul 2010
Location: The Mojave Desert Palmdale Ca. U.S.A.
Posts: 5,181
The sending unit(110%, OEM, POS)is on the left side of the pictures.
BTW, NEVER use Teflon tape on these, as they need a good ground(GND)for the electrical circuit.
LG
__________________
Have'n you along, is like loose'n 2 good men
LumpyGrits is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 11:45 AM   #5
WindKnot
Web Wheeler

WindKnot's Avatar
1977 CJ7

Join Date: Mar 2011
Location: Kaibab Plateau, Northern Arizona
Posts: 3,100
Mine works just fine with zero resistance. It was also just around one lap and not half the roll. the Teflon will tear if it's thin enough.
__________________
I'd rather be lost on the trails than found at home!

Phoenix Rising- A Flame Off Restoration? http://www.jeepforum.com/forum/f8/ph...ation-1807257/
WindKnot is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 11:50 AM   #6
LumpyGrits
Registered User
1985 CJ7

Join Date: Jul 2010
Location: The Mojave Desert Palmdale Ca. U.S.A.
Posts: 5,181
When I used the brass pipe, it cracked in a yr of Jeep'n
Went to a steel pipe, and no issues.
LG
__________________
Have'n you along, is like loose'n 2 good men
LumpyGrits is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 12:20 PM   #7
wsmutch
Registered User
1986 CJ7

Join Date: Apr 2013
Location: Marquette, MI.
Posts: 142
So, the wire on to goes to the gauge and the three prong is not necessary to get a reading at the dash?
wsmutch is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 12:35 PM   #8
LumpyGrits
Registered User
1985 CJ7

Join Date: Jul 2010
Location: The Mojave Desert Palmdale Ca. U.S.A.
Posts: 5,181
Correct
LG
__________________
Have'n you along, is like loose'n 2 good men
LumpyGrits is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 05:25 PM   #9
86cj74.2L
Web Wheeler

86cj74.2L's Avatar
2004 WJ

Join Date: Jul 2006
Location: Stouchsburg, PA
Posts: 7,159
I put a mechanical Stewart Warner Gauge in the CJ when the sending unit died.

With the copper hook up kit I bought it will last forever.

86cj74.2L is online now   Reply With Quote Quick reply to this message
Unread 08-21-2013, 07:09 PM   #10
LumpyGrits
Registered User
1985 CJ7

Join Date: Jul 2010
Location: The Mojave Desert Palmdale Ca. U.S.A.
Posts: 5,181
I did the same thing, after the second sending unit died while the Jeep was still in warranty.
LG
__________________
Have'n you along, is like loose'n 2 good men
LumpyGrits is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 07:35 PM   #11
keith460
Jeep. There's Only One

keith460's Avatar
1984 CJ7

Join Date: Jan 2007
Location: Doylestown, PA
Posts: 5,026
The three prong plug is for the Electric Choke Switch, but don't recall it being 3 prong as it is a more common 2 prong switch. It allows voltage to be applied for the coil of the Manifold Heater and carburetor Electric Choke.

If you are worried about what your actual oil pressure is and find that the OEM gauge is not accurate or functioning properly, do yourself a favor and add a small liquid filled pressure gauge to the side of the engine block so you can know at a glance whether oil pressure is present and at what the current pressure is at.

I used a small liquid filled pressure gauge that I bought from McMaster-Carr.com and added a 1/8 NPT thread to the existing pipe union for the Oil Pressure Sending Unit and Choke Switch.









The gauge in the picture is not liquid filled as it was changed out shortly after taken the photo.
__________________
.
1984 CJ-7 Renegade
__________________

Restoration Thread:http://www.jeepsunlimited.com/forums...d.php?t=434226
keith460 is offline   Reply With Quote Quick reply to this message
Unread 08-21-2013, 07:59 PM   #12
LumpyGrits
Registered User
1985 CJ7

Join Date: Jul 2010
Location: The Mojave Desert Palmdale Ca. U.S.A.
Posts: 5,181
Hey Keith, nice idea!
BTW, why don't you run that battery gnd to the top mounting bolt of the starter. Nut'n but good when you do.
LG
__________________
Have'n you along, is like loose'n 2 good men
LumpyGrits is offline   Reply With Quote Quick reply to this message
Unread 09-07-2013, 08:20 PM   #13
70worm
Registered User
1977 CJ5

Join Date: Jan 2012
Posts: 171
Can someone tell me how the wires hook up on the back of the gauge?
70worm is offline   Reply With Quote Quick reply to this message
Unread 09-07-2013, 09:39 PM   #14
titomars
Registered User
1981 CJ7

Join Date: Aug 2009
Location: Santa Rosa, California
Posts: 1,803
Quote:
Originally Posted by 70worm View Post
Can someone tell me how the wires hook up on the back of the gauge?
Red wire to positive terminal
Purple to neg or to sender
Orange for gauge light
