Head light upgrade installed and blinkers repaired.

I upgraded a friends head light wiring for him the other day.. I figured this would take 30 minutes but forgot that under his hood is a ton of extra wires and plumbing. Normally the relays go on the passenger side fender but unfortunatley there was no room so I got creative. Heres the mess on his fender



I probably could have squeezed in in a few spots but Ididnt want to make it look all clutttered so I stashed the relays here



The fuse holder were pulled through the hole in the grill and mounted



While I was going through his wiring I noticed his stock head light wires were cracked and had a few areas where they were crimped that looked a little shady so instead of using a socket for the stock plug to activate the relays I ran new wires and stripped back his split loom till I found some good wires and weather packed the head light connection.


His blinker and marker light wires were also cracked and broken with a few areas of exposed wires. Luckily i had some extra 14 ga wires and packard 56 terminals in my box so I rewired his blinkers and markers using a weather pack connector to mate em to the stock wires



When it is all said and done I ended up with this


I tested the voltage to his plugs before and after the install. before it was 11.6, after it went to 12.7 which is actually low. Normally it comes up to 14.0 after a few quick probes found his alternator to only be putting out 12.8-12.9 volts at the charging lug. I didnt get the chance to take before pics but heres the after

Low


High


Those sheds are about 200 feet away from the jeep. Heres a pic from the shed looking back at the jeep


What do you think??

__________________
88 YJ 35's 8.8 rear, family style roll bar, ax-15 external slave conversion, Custom double D fab dash 4" of lift taurus fan, Head light wiring upgrade, MSD 6al, JB conversions SYE, 258 with RV cam, Long tube headers, Borla exhaust. 1"mm, Auto meter gauges.
jimbos76cj is offline   Reply With Quote Quick reply to this message
Unread 08-27-2013, 04:13 PM   #2
bradleybrb
Member

bradleybrb's Avatar
1975 CJ5

Join Date: Jan 2013
Location: , MS
Posts: 485
Looks good to me!
bradleybrb is offline   Reply With Quote Quick reply to this message
Unread 08-27-2013, 08:36 PM   #3
Guy Smilie
Member

Guy Smilie's Avatar
1978 CJ5

Join Date: Aug 2010
Location: Salem County, New Jersey
Posts: 369
I like it. So this harness you made up grades the head lights and the blinkers?
Guy Smilie is offline   Reply With Quote Quick reply to this message
Unread 08-27-2013, 09:23 PM   #4
superj
Registered User
1987 YJ Wrangler

Join Date: Mar 2008
Location: corpus christi, texas
Posts: 6,717
Mine worked just as badass that I got from jimbos76cj. Huge difference in light output and color. No more yellow lights, now they are a solid white. (And a little low, ignore that)

__________________
Slow ride, take it easy
superj is offline   Reply With Quote Quick reply to this message
Unread 08-28-2013, 03:57 PM   #5
jimbos76cj
Registered User
1989 YJ Wrangler

Join Date: Jun 2007
Location: Florida
Posts: 436
Quote:
Originally Posted by Guy Smilie View Post
I like it. So this harness you made up grades the head lights and the blinkers?
there was no upgrading of the blinker and marker lights.. Just rewired.
__________________
88 YJ 35's 8.8 rear, family style roll bar, ax-15 external slave conversion, Custom double D fab dash 4" of lift taurus fan, Head light wiring upgrade, MSD 6al, JB conversions SYE, 258 with RV cam, Long tube headers, Borla exhaust. 1"mm, Auto meter gauges.
