I went with 2in x 1in 3/16 square tubing for the crossmember. Since the original was nothing close to that I think it should be fine.

Also please feel free to not point out my terrible welds...lol. It was the first time I used as gas 220 set up and it took a line to dial it in.

imag0844.jpg   imag0845.jpg   imag0846.jpg
