Unread 04-04-2012, 01:52 AM   #751
kllshadow
Registered User
2006 WK

Join Date: May 2011
Location: Altoona, PA
Posts: 367
Nice! Can't wait to see the pics. What kind of graphite paint do you use?

__________________
06 WK Limited--5.7 Hemi--QDI--Ebay Catch can--RC 2" lift--265/70/17 Cooper STT--Expanded Sheet Grill--Magnaflow muffler--Volant CAI--1.5" Spidertrax--Monroe LLs--4x Guard Front Skid--Superchips Tuned--
kllshadow is offline   Reply With Quote
Unread 04-04-2012, 11:21 AM   #752
Omelet
Evil Overlord!

Omelet's Avatar
2005 WK

Join Date: Mar 2009
Location: San Diego, CA.
Posts: 5,154
This:




I am uploading pics right now, so I will post them in a few mins!
__________________
See How It Was Made

HEMI Club Member #31 - - - JEEP Makes It, HEMI Shakes It!!!
Omelet is offline   Reply With Quote
Unread 04-04-2012, 11:30 AM   #753
JeepN4KC
Keep on Jeepin on........

JeepN4KC's Avatar

Join Date: Jul 2011
Location: Blue Springs, MO
Posts: 5,090
Waiting with baited breath.
__________________
~Mike~

My Build Thread WK
My Other Build Thread XJ
'01 XJ with some stuff
Sept 2013 Cherokee of the Month
'07 WK with some other stuff
~RED WK CLUB #7~
'11 KK with mostly stock stuff
'06WK our first Jeep with stock stuff - totalled and gone
JeepN4KC is offline   Reply With Quote
Unread 04-04-2012, 11:40 AM   #754
gunnerscherlin
Registered User
2005 WK

Join Date: Apr 2010
Location: Casper, WY
Posts: 215
the suspense is killing me!!
__________________
2005 WK Limited HEMI , 2 Hella 4000 HID SPOT, Alpine Stereo
Magnaflow Exhaust
Future Mods: OME HD, 285/70/17 Goodyear duratracs, and CAI
gunnerscherlin is offline   Reply With Quote
Unread 04-04-2012, 11:53 AM   #755
S1L3NT_WH33L3R
Registered User
2005 WK

Join Date: Oct 2009
Posts: 779
CMOoooooooooooooN
__________________
'05 WK Limited, QD-II, 5.7L HEMI, Volant Cold Air Intake, Aries Taillight Guards, Rola Roof Rack, Cobra CB, Firestik Antennas, Magnaflow Performance Exhaust, OME HD lift, 285/70-17 GY Duratracs, Spidertrax Spacers, Superchips Programmer, Steel Armadillo Super Sliders
~Jeep makes it HEMI shakes it~Ain't Nothing Humble about that HEMI Rumble~
S1L3NT_WH33L3R is offline   Reply With Quote
Unread 04-04-2012, 11:55 AM   #756
mattydipps
Registered User
2006 WK

Join Date: Sep 2011
Location: west babylon, new york
Posts: 1,512
I've been checking my phone every half hour !!
__________________
Sold-
mattydipps is offline   Reply With Quote
Unread 04-04-2012, 11:55 AM   #757
Omelet
Evil Overlord!

Omelet's Avatar
2005 WK

Join Date: Mar 2009
Location: San Diego, CA.
Posts: 5,154
So yesterday I finished up the front end by installing the break line extensions, the belly pan, and doing a quick alignment.

Driver side:




Passenger side:



Here is the belly pan:




A little heavier than the aluminum one I had before I had a hard time with the tab nuts they include for the two center bolts. First they did not weld the nut in the middle of the hole in the tab, so I couldn't get the bolt in. I took a dremel to it and very carefully ground the hole bigger so the bolt would go in.




Then the tab nut is supposed to slide into a slot in the crossmember and line up with the bolt hole in the belly pan, but it wasn't lining up right. I had to grind down one of the welds on the nut so it would fit properly.




After that I lowered the Jeep to the ground and did a quick alignment. I will take it in later this week and get a real alignment. Once on the ground it measured in at just over 25" which is what I was shooting for




After that I moved onto the rear. I don't have very many pics because I did most of the instal work at night. I still need to go back out and torque all the control arm bolts down. Here is a comparison between the OME HD rear coil (right) and the new SL rear coil (left).





The OME measured 13.5" where as the SL measured 16". After lowering the rear down to the ground it measured in at 24". I might through another coil isolator in there or a thin spacer to bring it up level with the front. Not sure yet, I still need to let everything settle into place.

__________________
See How It Was Made

HEMI Club Member #31 - - - JEEP Makes It, HEMI Shakes It!!!
Omelet is offline   Reply With Quote
Unread 04-04-2012, 12:10 PM   #758
sixfoot9psu
Registered User
2005 WK

Join Date: Dec 2011
Location: York, PA
Posts: 503
nice work! definitely a much bigger job than i'd ever tackle myself
__________________
'05 GC 5.7L Hemi QDII...Rock Krawler lift, 4XGuard Matrix, rock sliders, front and rear skids, belly guard, rear diff guard, Bilstein HDs, Volant intake, 265/70 Goodyear DuraTracs, Superchips, Rola roof rack, BORA wheel spacers, Rocky Road Leveling Spacers, Magnaflow muffler, KC Slimlights, BT catch can, tb cover, and underhood kit, Expanded Sheet Metal Grille
[URL="http://www.jeepforum.com/forum/f67/sixfoot9psus-build-thread-1341203/"]Build Thread[/URL]

'09 G8 GT 6.0L...Kooks Headers, Rotofab intake, SLP exhaust, Vector Motorsports Tune
sixfoot9psu is offline   Reply With Quote
Unread 04-04-2012, 12:17 PM   #759
CmmdrDan
Registered User

Join Date: Sep 2010
Posts: 3,178
My new user name should be crusty pants..
CmmdrDan is offline   Reply With Quote
Unread 04-04-2012, 12:28 PM   #760
Omelet
Evil Overlord!

Omelet's Avatar
2005 WK

Join Date: Mar 2009
Location: San Diego, CA.
Posts: 5,154
Quote:
Originally Posted by sixfoot9psu View Post
nice work! definitely a much bigger job than i'd ever tackle myself
Thanks! It is definitely a big job. Almost finished!


Quote:
Originally Posted by CmmdrDan View Post
My new user name should be crusty pants..
I am officially freaked out now
__________________
See How It Was Made

HEMI Club Member #31 - - - JEEP Makes It, HEMI Shakes It!!!
Omelet is offline   Reply With Quote
Unread 04-04-2012, 12:34 PM   #761
JeepN4KC
Keep on Jeepin on........

JeepN4KC's Avatar

Join Date: Jul 2011
Location: Blue Springs, MO
Posts: 5,090
Nice work Nathan - very nice!

The WK looks great and your aptitude for tearing down and installing is top notch - very impressive.
__________________
~Mike~

My Build Thread WK
My Other Build Thread XJ
'01 XJ with some stuff
Sept 2013 Cherokee of the Month
'07 WK with some other stuff
~RED WK CLUB #7~
'11 KK with mostly stock stuff
'06WK our first Jeep with stock stuff - totalled and gone
JeepN4KC is offline   Reply With Quote
Unread 04-04-2012, 12:40 PM   #762
Omelet
Evil Overlord!

Omelet's Avatar
2005 WK

Join Date: Mar 2009
Location: San Diego, CA.
Posts: 5,154
Thanks bud! Now to finish up am move on to my next mod

__________________
See How It Was Made

HEMI Club Member #31 - - - JEEP Makes It, HEMI Shakes It!!!
Omelet is offline   Reply With Quote
Unread 04-04-2012, 01:17 PM   #763
BobG97
Registered User
2005 WK

Join Date: Dec 2010
Location: Piedmont, MO
Posts: 496
I like it! So that's a combination of OME and SL kits or would one expect a SL kit to sit similar to this once it was finished?
BobG97 is offline   Reply With Quote
Unread 04-04-2012, 01:37 PM   #764
Omelet
Evil Overlord!

Omelet's Avatar
2005 WK

Join Date: Mar 2009
Location: San Diego, CA.
Posts: 5,154
I have the OME coils up front, but they are cut shorter and I have extra weight from the winch. The rear is standard height at 24" using only the SL coils. Depending on what shocks and coils you use up front and what additional weight you have, you should see around 24-25". Could be more, could be less, just depends one the setup.
__________________
See How It Was Made

HEMI Club Member #31 - - - JEEP Makes It, HEMI Shakes It!!!
Omelet is offline   Reply With Quote
Unread 04-04-2012, 01:56 PM   #765
CmmdrDan
Registered User

Join Date: Sep 2010
Posts: 3,178
Quote:
Originally Posted by Omelet View Post
Thanks bud! Now to finish up am move on to my next mod

What is that?
CmmdrDan is offline   Reply With Quote
