Unread 10-30-2013, 08:37 PM   #166
Boundless
Registered User
2005 LJ Wrangler

Join Date: Feb 2008
Location: Satellite Beach, Florida
Posts: 1,063
wow awesome build

__________________
__________________________________________
Rusty
Satellite Bch, FL
2005 Jeep Wrangler Unlimited (LJ) 6cyl, 4spd auto, dana 30/44 3.73, rear trac-loc, hard top, BFG KM2 35/12.5 x 15 on rattle can black stock Ravine wheels & 1.5" spacers, trimmed flares, budget PA 1" BL & RC 1" MML, Ford Explorer roof rack, Hella e-code headlight housings, 55 watt DDM HID Hi/Lo 6000k, EBC Yellow Stuff front brake pads, Platinum P4 battery, Rusty's 3" 305s front and 303s rear springs, RC rear track bar bracket and Hella 500FFs with DDM's 55watt 6000k H3 HIDs on windshield hinge brackets. Currie's front upper and lower control arms. Hummm whats next? Building a Dana HP30 with 4.88 and ? locker
http://www.canddautocenter.com/
Boundless is offline   Reply With Quote Quick reply to this message
Unread 10-30-2013, 09:36 PM   #167
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Quote:
Originally Posted by Boundless View Post
wow awesome build
Thanks , its been fun but I am looking forward to working on something else for a while .




New shackles painted and installed . I now have plenty of travel and adjustability if needed .

Everything is lined up and ready to go .

Ranger center caps with a custom steel insert .



The tub is mounted and complete except for the tail lights which will get plugged in tomorrow morning . With a little luck I can make it over to DMV and get inspected tomorrow morning . Many thanks to Hendrix for all the body and paint work and to Jonathon for helping me along the way .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 10-31-2013, 02:59 PM   #168
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
So after a bit of worrying about the inspection process the angry trailer passed with nary a problem. The State Highway Patrolman gave it a once over , checked to see that the vin was stamped in the proper place and then asked me "did you really build this"? That was nice to hear , and I told him yes except for the fact that I brought in a ringer for the paint and body work . I have had people all day long waving and pointing , its a little surreal . No videos were taken yet , so I dont have dumpster status .

It tows good , but wags a little at speed due to the fact that I have too much play in the multi axis hitch . I am going to re build it on the mill and get tighter tolerances over the winter . Until then I am going to run a bolt on traditional coupler .


The trailer sits just a little higher than the LJ which means it should be near dead level once its loaded .








I towed it about 40 miles on road and mile or so off road and it does fine other than a little wagging like I mentioned above . I am off to fix that after trick or treating tonight .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 10-31-2013, 10:08 PM   #169
aw12345
Web Wheeler
2004 TJ Wrangler

Join Date: Oct 2006
Location: ontario, Cali
Posts: 6,651
Quote:
Originally Posted by G Beasley View Post
So after a bit of worrying about the inspection process the angry trailer passed with nary a problem. The State Highway Patrolman gave it a once over , checked to see that the vin was stamped in the proper place and then asked me "did you really build this"? That was nice to hear , and I told him yes except for the fact that I brought in a ringer for the paint and body work . I have had people all day long waving and pointing , its a little surreal . No videos were taken yet , so I dont have dumpster status .

It tows good , but wags a little at speed due to the fact that I have too much play in the multi axis hitch . I am going to re build it on the mill and get tighter tolerances over the winter . Until then I am going to run a bolt on traditional coupler .


The trailer sits just a little higher than the LJ which means it should be near dead level once its loaded .








I towed it about 40 miles on road and mile or so off road and it does fine other than a little wagging like I mentioned above . I am off to fix that after trick or treating tonight .
i


Greg, wouldn't a bit of toe in on the axle solve the wagging.
Uncle of mine used to built trailers for a living and always toe'd the axles in a bit for good tracking. I doubt tightening the hitch parts will make much of a difference. Try it with a ordinary coupler, wouldn't be surprised if it would still wag
__________________
My Tinkering and wheeling thread http://tinyurl.com/pbwdm5u
aw12345 is offline   Reply With Quote Quick reply to this message
Unread 10-31-2013, 11:56 PM   #170
Rubicon0311
Registered User
2005 TJ Wrangler

Join Date: May 2012
Location: Kalamazoo, MI
Posts: 3,326
Looks great, glad to see it on it's own weight
__________________
[URL="http://www.jeepforum.com/forum/f22/rubicon0311-build-1470981/"][B]My 4.6 Stroker build[/B][/URL]

[URL="http://www.jeepforum.com/forum/f325/what-did-you-do-your-xj-mj-tj-zj-wj-wk-lj-jk-thread-1289204/"][B]Michigan BS Thread[/B][/URL]
Rubicon0311 is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 05:42 PM   #171
lar308
Member

lar308's Avatar
1990 YJ Wrangler

Join Date: Oct 2011
Location: Newark, Ohio
Posts: 284
A fine job Sir. You may want to try more tongue weight. Ron
lar308 is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 08:35 PM   #172
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Quote:
Originally Posted by aw12345 View Post
i


Greg, wouldn't a bit of toe in on the axle solve the wagging.
Uncle of mine used to built trailers for a living and always toe'd the axles in a bit for good tracking. I doubt tightening the hitch parts will make much of a difference. Try it with a ordinary coupler, wouldn't be surprised if it would still wag
I have 3 degrees of toe in , but there is no crown. The regular coupler is built and installed . Test towing tomorrow morning .

Quote:
Originally Posted by Rubicon0311 View Post
Looks great, glad to see it on it's own weight
It is nice to see it in a useable state

Quote:
Originally Posted by lar308 View Post
A fine job Sir. You may want to try more tongue weight. Ron
Thanks , and I am headed that direction once I install the tongue box .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 09:11 PM   #173
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Today I made a different tongue attachment and I installed the tailgate cables .

The multi axis coupler is attached to the tongue with a 5/8" shank grade 8 stud . This made it pretty easy to fabricate a traditional hitch to bolt to the tongue .

I cut a piece of 2"x2" box tube diagonally and welded an end it . Then I centered it up and drilled a hole so that it could be attached to the tongue . I welded what you see here and then all six of the plug welds on the top and sides .

All welded up and painted .

Installed and ready for a test tow . I think its going to make a huge difference as there is no play in the tongue now .

Next up was to get the tailgate cables installed before I screwed up and dropped the gate on the bumper ! After some rough measuring it seemed like the cables and hardware from an 04 explorer sport trac would work out just about perfect .

The Ford factory torx bolts thread right into the CJ tailgate , but they need to be trimmed down so that they clear the when opening and closing.

I had hoped to attach directly to the old inner fender but the tub flange pushed the cables out of alignment. Two pieces of 1.75 tubing and some slightly modified factory pivots allowed better alignment of the cables .



The explorer sport trac cables and hardware worked out nicely . I did make the spacers cam centric so that I could turn them to adjust the slack of the cable . Sounds silly ,but it made for easy adjustment .

Last but not least , no Monkeys were harmed in the fabrication of this trailer .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 09:25 PM   #174
Sahara707
Member

Sahara707's Avatar
2000 TJ Wrangler

Join Date: Aug 2011
Location: Petaluma, CA
Posts: 482
looks great! Any plans for mounting the spare to free up the trailer bed?
Sahara707 is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 09:32 PM   #175
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Quote:
Originally Posted by Sahara707 View Post
looks great! Any plans for mounting the spare to free up the trailer bed?
Thank you , and yes the spare will go back on the LJ once the tailgate hinges are reinforced .



Also made a minion for the kids while I was waiting on parts to dry for the trailer .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 11-01-2013, 10:13 PM   #176
Sahara707
Member

Sahara707's Avatar
2000 TJ Wrangler

Join Date: Aug 2011
Location: Petaluma, CA
Posts: 482
I went with a stock TJ carrier.

Sent from my iPad using JeepForum

__________________
[URL="http://www.jeepforum.com/forum/f27/amor-rex-inc-off-road-trailer-build-1558519/"]Amour Rex Off-Road Trailer Build[/URL]
Sahara707 is offline   Reply With Quote Quick reply to this message
Unread 11-02-2013, 06:53 AM   #177
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Quote:
Originally Posted by Sahara707 View Post
I went with a stock TJ carrier.

Sent from my iPad using JeepForum
I will be hauling the spare on the LJ . Thats what I was talking about beefing up . If I were to hide that painted tailgate Hendrix would put a hit out on me. The trailer and LJ use the same size tire and rim so I just need to carry one .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 11-02-2013, 09:16 AM   #178
green50gt
Senior Member

green50gt's Avatar
2001 TJ Wrangler

Join Date: Jun 2009
Location: Goshen, IN
Posts: 609
Looks great!
green50gt is offline   Reply With Quote Quick reply to this message
Unread 11-02-2013, 09:10 PM   #179
G Beasley
Registered User
2005 LJ Wrangler

Join Date: Nov 2001
Location: Eden, NC
Posts: 5,511
Quote:
Originally Posted by green50gt View Post
Looks great!
Thanks , has it inspired you to build another one yet ?

Today we took the trailer all over the county , even on the interstate so that I could get up to higher speeds . I am relieved to say that the trailer has no quirks at any speed now ! Heres some pics from the day .







It was a great day of towing around and running errands with nary a wiggle from the trailer .

When I get back from Minnesota the aluminum for the tonneau should be here and I still need to cut the tongue jack so that I can add some length .
__________________
Free stickers and picture hosting at Jeep-Owner.com
G Beasley is offline   Reply With Quote Quick reply to this message
Unread 11-02-2013, 09:17 PM   #180
ginger-mech
Registered User
1963 CJ5

Join Date: Aug 2012
Location: Annapolis, MD
Posts: 66
The shots in the woods are great. I love autumn. Great work.
ginger-mech is offline   Reply With Quote Quick reply to this message
