post #47 of 57 Old 10-23-2012, 07:38 PM Thread Starter
Boreal
Web Wheeler

Boreal's Avatar
2008 JK Wrangler

Join Date: Nov 2006
Location: Central
Posts: 3,053
Haven't updated in a while...










Close up of the dovetail. I didn't get a pic of the 3 bolts used to mate the ramp to the bed on the top side... there are 3 nuts welded to the inside of the bed where the bolts connect, and another 2 smaller nuts on the outside of the bed where you can rest the ramps while starting the bolts. Undo the 3 bolts and the hitch pin on the bumper, and the whole ramp will just pop off.


This is a little piece of 1"x1" tubing that helps transfer a little of the weight (especially during loading). Also visible is a long piece of 3"x3" tubing welded under the bed to strengthen it. I've seen similar setups where the flatbed has significant flex in it when the rig is loaded... we were trying to avoid that.

Still to come are reverse lights on the headache rack, airbags, relocating the license plate, ball cam, and finish wiring the trailer light plug near the passenger taillight (one coming out of the hitch is going bye bye).
