post #196 of 1199 Old 11-23-2010, 07:27 PM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878
back in the dirt where she belongs




TJdualsport is offline
Sponsored Links
Advertisement

post #197 of 1199 Old 11-29-2010, 05:33 PM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878



TJdualsport is offline
post #198 of 1199 Old 11-29-2010, 06:09 PM
Hendrix
TJOTY 2013

Hendrix's Avatar
1997 TJ Wrangler

Join Date: Apr 2009
Location: FT Myers
Posts: 4,866
Again those are some great Vids.
Hendrix is offline
post #199 of 1199 Old 11-29-2010, 06:40 PM
djflyy
Registered User
1999 TJ Wrangler

Join Date: Mar 2008
Location: Boston
Posts: 3,506
Awesome build, and those videos kick a$$. It's such an interesting perspective to get while driving. I don't think I've seen another build that's gone in the direction yours has.
djflyy is offline
post #200 of 1199 Old 11-29-2010, 07:12 PM
J-B
Registered User
1998 TJ Wrangler

Join Date: Dec 2008
Location: Florence Al
Posts: 268
I love this jeep!

98 TJ 4.0, 31's, 3.73, and stock.
88 F150 4.9, 29's, 3.55, and Flat Black
99 Ram 5.9 31's DD


http://www.jeepforum.com/forum/f22/e...ammy-j-935630/
J-B is offline
post #201 of 1199 Old 11-29-2010, 07:13 PM
OtterJeep
Registered User
2000 TJ Wrangler

Join Date: Aug 2010
Location: La Mesa
Posts: 28
maybe its my ****ty work computer, but I can't see any pics except the ones on this page. The Jeep sounds AWESOME, now I want to see it, anyone else having this problem?
OtterJeep is offline
post #202 of 1199 Old 11-29-2010, 10:46 PM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878
thanks, guys. ive been cleaning and cleaning the jeep up after that trip. the salt lake bed crossing was nasty. just gotta do an alingment and the jeep is back on the street. as soon as time permits i will be adding the 8.8 and bump stops asap. its sad its all just sitting in the garage waiting to go in
TJdualsport is offline
post #203 of 1199 Old 11-30-2010, 02:06 AM
mJUSTINm
Registered User
2006 LJ Wrangler

Join Date: May 2008
Location: lakewood, ca
Posts: 2,268
God that salt lake bed was a muddy mess on the way back. That was fun.

-Justin | Bruised LJ Build
mJUSTINm is offline
post #204 of 1199 Old 11-30-2010, 03:57 AM
mxtrails
Registered User
2003 TJ Wrangler

Join Date: Feb 2009
Location: Shelby Township
Posts: 152
what bump stops do you have? i've been looking into some bumps for my rig. it looks like the teraflex speed bumps work well on jk's. those are pretty much the same concept as the daystar stinger bump also but much more affordable. so i was thinking about installing a set of those in the front of my tj (looks pretty easy). not sure yet how to fit a set in the rear though. how do you plan to set that up?

03 Rubicon, highlined rear fenders, RC long arm upgrade, 4" RC springs, OME shocks, 35" mt's, UCF lopro trans mount, UCF 2" deep skid, nates 4x4 rear bumper/tire carrier, 2" jks bumpstops, jks discos, RK frt track bar, tom woods cv. rebuild pics: http://s61.photobucket.com/albums/h57/mxtrails/Jeep/
mxtrails is offline
post #205 of 1199 Old 11-30-2010, 10:06 AM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878
currently stock. I have a set of bilsteins and am looking for another pair. those internal foam bumps i hear work pretty well. I like how you can add take away or swap out internal pucks to soften or stiffen the bump stop on the stingers. those matched up with some beefy shocks would work pretty well IMO. im going with the bilstiens because of the abuse they can take. still up in the air how the foam ones will hold up over time and have yet to see them in action over woop sections. the rear is kinda tricky, the only real correct way of doing it is cutting off the upper coil mount and repositioning it so it makes the coil go straight up and down. then you can mount your bump in the coil just like the front. the biggest thing you have to be careful with is making sure your not riding on your bumps and that your bumpstop bottoms out before your shocks do. the other thing to watch for is coil spring contact on the bumpstop shock body. ill be posting pics when i get mine done and will be doing the rear first.
TJdualsport is offline
post #206 of 1199 Old 11-30-2010, 03:12 PM
mxtrails
Registered User
2003 TJ Wrangler

Join Date: Feb 2009
Location: Shelby Township
Posts: 152
i've already been planning on moving the upper rear spring bucket rearward. i'd probably also outboard the shocks then as well. but for the bumpstop to mount in the center of the coil, won't you have to cut a 2" hole through the frame? i guess it wouldn't affect the structure of the frame vertically but horizontally it will be compromised. do you plan to brace the frame around that area? or is there enough room to butt the bumpstop end against the frame without recessing it?

03 Rubicon, highlined rear fenders, RC long arm upgrade, 4" RC springs, OME shocks, 35" mt's, UCF lopro trans mount, UCF 2" deep skid, nates 4x4 rear bumper/tire carrier, 2" jks bumpstops, jks discos, RK frt track bar, tom woods cv. rebuild pics: http://s61.photobucket.com/albums/h57/mxtrails/Jeep/
mxtrails is offline
post #207 of 1199 Old 12-01-2010, 12:24 AM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878
yea then i would weld the can in place with a pinch at the bottom. I may plate the frame but it kinda depends on how it all comes together when i get into it.
TJdualsport is offline
post #208 of 1199 Old 12-09-2010, 06:01 PM Thread Starter
TJdualsport
Registered User
2002 TJ Wrangler

Join Date: Oct 2009
Location: OC
Posts: 2,878
finally wired up the light in the gauge. lol ive done like 4 in the last couple months for other people but never finished mine...
TJdualsport is offline
post #209 of 1199 Old 12-09-2010, 06:20 PM
adamjstone
Registered User
2006 TJ Wrangler

Join Date: Dec 2010
Location: temecula
Posts: 3
awsome

this looks amazing keep it up
adamjstone is offline
post #210 of 1199 Old 12-09-2010, 06:20 PM
adamjstone
Registered User
2006 TJ Wrangler

Join Date: Dec 2010
Location: temecula
Posts: 3
Quote:
Originally Posted by TJdualsport View Post



haha you can never go wrong with CJ ever. Looks like you guys had alot of fun
adamjstone is offline
