Unread 08-09-2011, 07:42 AM   #586
comptiger5000
Registered User
1998 ZJ

Join Date: Jan 2009
Location: Stamford, CT / Rochester, NY
Posts: 4,146
The hex plugs for fill/drain are 10mm, IIRC.

comptiger5000 is offline   Reply With Quote
Unread 08-10-2011, 09:08 PM   #587
jaguarjoe
Registered User
1995 ZJ

Join Date: Jul 2011
Location: Grosse Ile, MI
Posts: 257
Everybody sez to get a good pair of snap ring pliers to do this swap. Are all these snap rings the external type? Are the pliers straight or 90 degree?

Can anyone just give me a name and model number for a good pair?
jaguarjoe is offline   Reply With Quote
Unread 08-13-2011, 12:26 PM   #588
JordanZJ
Registered User
1998 ZJ

Join Date: Jul 2011
Location: n, Ca
Posts: 6
I have a 98 zj with the 294 thats going out. My donor is a 231 from 95. The input length on the 231 is .750 adn the 249 is .840. Do i use the 249 shaft in the 231 case?
JordanZJ is offline   Reply With Quote
Unread 08-13-2011, 04:58 PM   #589
corndogduff
Registered User
1992

Join Date: Dec 2008
Location: Mormonville, UT
Posts: 3,330
Quote:
Originally Posted by jaguarjoe View Post
Everybody sez to get a good pair of snap ring pliers to do this swap. Are all these snap rings the external type? Are the pliers straight or 90 degree?

Can anyone just give me a name and model number for a good pair?
Just get a good universal set (craftsman makes a pair that I've used EVERYWHERE) and you'll be golden. Get some lock ring pliers too. Using snap ring pliers on lock rings is a quick way to break tools.
__________________
Duff.
(broken)98 ZJ 5.9
UT Jeepcrew #13
NIGHTCREW
corndogduff is offline   Reply With Quote
Unread 08-13-2011, 04:59 PM   #590
corndogduff
Registered User
1992

Join Date: Dec 2008
Location: Mormonville, UT
Posts: 3,330
Now for my question. Anyone know if an XJ rear DS would fit after a 231 swap? My DS is WAAAAAYYYYY too long to fit.
__________________
Duff.
(broken)98 ZJ 5.9
UT Jeepcrew #13
NIGHTCREW
corndogduff is offline   Reply With Quote
Unread 08-13-2011, 06:11 PM   #591
ZJFABN
Registered User
1996 ZJ

Join Date: Oct 2009
Location: ARIZONA
Posts: 228
Quote:
Originally Posted by JordanZJ View Post
I have a 98 zj with the 294 thats going out. My donor is a 231 from 95. The input length on the 231 is .750 adn the 249 is .840. Do i use the 249 shaft in the 231 case?
You dont need to swap anything. Thats too close to even worry about.
__________________
My work, http://www.virtualjeepclub.com/showthread.php?70963-JW-Fabrication&highlight=Jwfabrication
ZJFABN is offline   Reply With Quote
Unread 08-18-2011, 03:25 PM   #592
MuddSlutt
Registered User
1998 ZJ

Join Date: Mar 2010
Location: Farmington, CT, Connecticut
Posts: 480
just did my 242 swap in my 98 5.9... donor was a 96.5 zj with an external slip yoke, swap went well minus me F'in up the output shaft seal. the only problems i ran into was the rear DS which i ended up just cutting the shaft on the TC and cutting the yoke on the DS, and the current problem i have is there are no 4wd light turning on in my VIC (before and after a swaped the red and black plugs)... any thoughts? bad switch?

__________________
1998 ZJ 5.NINER Limited
"JEEPING... Because football, baseball, basketball, and soccer only require one ball."
[B][_]I II II II I[_][/B]

Brass Balls Offroad

[COLOR="Black"][CENTER][SIZE="4"][FONT="Showcard Gothic"][COLOR="Black"][URL="http://groups.jeepforum.com/built-not-bought/"][COLOR="Black"]Built Not Bought #560[/COLOR][/URL][/FONT][/SIZE][/COLOR][/CENTER][/COLOR]
MuddSlutt is offline   Reply With Quote
Unread 08-18-2011, 11:45 PM   #593
Travis873o
Registered User
1996 ZJ

Join Date: May 2008
Location: Knoxville, TN
Posts: 925
Did anyone ever figure out how to wire the 2 prong 231 shift sensor plug to the 4 prong 249 plug?
__________________
Built not Bought #170
My build thread:
http://www.jeepforum.com/forum/f197/...hread-1295705/
FOR SALE: ZJ 231 bezel,
PM me if you need one.
Travis873o is offline   Reply With Quote
Unread 08-19-2011, 02:37 PM   #594
csouers
Registered User
1999 XJ Cherokee

Join Date: Feb 2008
Location: Bloomington, Indiana
Posts: 2,020
Quote:
Originally Posted by Travis873o
Did anyone ever figure out how to wire the 2 prong 231 shift sensor plug to the 4 prong 249 plug?
Wire the corresponding wires to each other. Seems like that would work.
__________________
1998 Bright Platinum ZJ 5.9 Limited - 5.9l, 46RE, NV-242, D30/44a (Trac-Loc) w/3.73s - The DD
1999 White XJ Sport - 4.0l, AW4, NP-231, D30/8.25 w/3.55s - The Rig

My Photography
csouers is offline   Reply With Quote
Unread 08-19-2011, 03:30 PM   #595
Travis873o
Registered User
1996 ZJ

Join Date: May 2008
Location: Knoxville, TN
Posts: 925
Quote:
Originally Posted by csouers View Post
Wire the corresponding wires to each other. Seems like that would work.
Could you go a little more in detail? Which wires are you talking about? I have 4 to choose from when I can only use two. How do you know which ones that correspond to the 2 prong plug?
__________________
Built not Bought #170
My build thread:
http://www.jeepforum.com/forum/f197/...hread-1295705/
FOR SALE: ZJ 231 bezel,
PM me if you need one.
Travis873o is offline   Reply With Quote
Unread 08-19-2011, 09:28 PM   #596
JrMechanic
Registered User
1993 ZJ

Join Date: Oct 2008
Location: Lima, Ohio
Posts: 3,368
I currently have two Selec-Trac bezels for sale, $25 shipped a piece.



Here's a good visual for those of you unsure of the different input lengths. From the left, I have a 1.55" input from a 249, a .840" input from a 231, and finally a .750" input from a 242. They are all 23 spline shafts with the old style gear cut and they are all three interchangeable between each case.

A word of caution to those who attempt installing a .750" input in place of a .840" input: If you look closely at the center (.840") input, you'll see the upper most wear ring on the input. This is where the transmission output seal rides on the input shaft. As you can see, it's not very far from the edge of the shaft (approximately 3/10ths of an inch). If you attempt this swap, I recommend sealing the transmission and transfer case surfaces with Ultra Black or Gray RTV. I recommend this if your rig sees any deep mud or water anyways to keep sediment from ruining the transfer case and transmission seals.

__________________
Want to swap an NP242 or NP231 into your ZJ? Here's how:
http://www.jeepforum.com/forum/f13/n...pdated-685644/
JrMechanic is offline   Reply With Quote
Unread 08-19-2011, 10:40 PM   #597
Travis873o
Registered User
1996 ZJ

Join Date: May 2008
Location: Knoxville, TN
Posts: 925
So i figured out how to wire in the 231 sensor with the zj. Works and shows 2wd and part time 4wd. will be posting pictures and a how to some time tomorrow.
__________________
Built not Bought #170
My build thread:
http://www.jeepforum.com/forum/f197/...hread-1295705/
FOR SALE: ZJ 231 bezel,
PM me if you need one.
Travis873o is offline   Reply With Quote
Unread 08-20-2011, 11:06 AM   #598
Travis873o
Registered User
1996 ZJ

Join Date: May 2008
Location: Knoxville, TN
Posts: 925
Alright so I figured out how to wire up the 2 prong sensor from the 231 with the 4 prong wires from the 249. It's a lot simpler than you may think.

Alright so first off, you have to disconnect the red plugs behind the VIC and connect the black ones as the original writeup describes. All this action does is interpret the signal from the sensor differently. When the red plugs are connected (with the 249) the signal is interpreted as "4wd Lo". And when the black ones are connected it interprets the signal as "2wd", "Full-Time" and "Part-Time". Now when I say the sensor sends a signal, it's not really a signal, all it's doing is completing a existing circuit.

Alright so first you'll have to cut the 4 prong harness off and strip the 4 wires so you can do some splicing. then you'll have to connect the two wires you see in the first picture. Just twist them together for now. What this does is completes the circuit telling the VIC that you are in 2wd. the rear tires should be lit up on the VIC.

NOTE: I am unable to tell you the colors of these wires as...I'm colorblind, I was surprised I was able to figure this out as wiring, as you can imagine, is quite difficult for me.

So now cut the exposed wire completely that you see in the first picture...the one all the way to the right. You wont be using this. This wire is for the 242's "Full-Time" feature.

So now, while looking at the first picture, if you were to connect the all three wires the VIC would think you are in "4wd Part-time". So all the sensor really does is connect these three wires.

So splice the two wires from the 231 harness to the 2 wires you now have. See second picture.

NOTE: it does not matter which wires you use from the 231 harness because it's just jumping the wires together when the sensor is activated.

Now you're done test it with the sensor connected and when you depress the button on the sensor it should be in "part time" and when you release the button it should be in 2wd.
2011-08-19_21-34-23_445.jpg   2011-08-19_21-55-28_15.jpg
__________________
Built not Bought #170
My build thread:
http://www.jeepforum.com/forum/f197/...hread-1295705/
FOR SALE: ZJ 231 bezel,
PM me if you need one.
Travis873o is offline   Reply With Quote
Unread 08-26-2011, 12:29 PM   #599
skimsurf
Registered User
1990 YJ Wrangler

Join Date: Jun 2008
Location: pa
Posts: 264
looking to do this t-case swap on a 96 v8...should have the 249, since that is what everything i have found says. its a v8 not sure what size, guessing 5.2...im trading my 2k pos bravada for it...this guy thought it was a good buy sold my 94 yj, and 96 xj, still kicking myself for it, to buy it...tired of beating my head against the wall when the damn car keeps stalling after being run for an hr...anyway, I want to do the swap so I am not running in 4wd all the time, $3.50+ a gallon would like to save some cash...so what years in the t-cases should i be looking for? I found one out of a 99...pretty much all i could find...but i am not 100% sure...i get lost in a lot of the specs, after reading so many threads they all run together...the t-case out of a zj is the same deal, but with the v8 and i6 what kind of swaps in the tcase will i have to make? help, what kinda donor do i need to look for to make this as painless as possible?
skimsurf is offline   Reply With Quote
Unread 08-26-2011, 12:56 PM   #600
JrMechanic
Registered User
1993 ZJ

Join Date: Oct 2008
Location: Lima, Ohio
Posts: 3,368
You won't gain any fuel mileage, so if that's your only motive for this swap then forget it. However if the VC is locked up (which it almost certainly will be), then swapping transfer cases is a good option.

A '99 will not work unless it is from an XJ and it has the speedometer provision. You want a 96-98 242 and will need to address the rear drive shaft only, or if you get lucky enough and find a 93-95 ZJ 242 with the .840 input shaft and internal rear slip yoke it will be a direct swap.
__________________
Want to swap an NP242 or NP231 into your ZJ? Here's how:
http://www.jeepforum.com/forum/f13/n...pdated-685644/
JrMechanic is offline   Reply With Quote
