rod bearing replacement .ASAP PLEASE

Well I figured out i had a rod bearing spun. I,ve got everything cleaned up and all new rod bearings in. I need torque specs for the rod cap bolts. All data says 15 lbs then 110 degrees. Measuring degrees with a rachet is a damn nightmare. Anyone replaced theres and what did you torque them to?

twistedgalant is offline
Sponsored Links
Advertisement

post #2 of 17 Old 12-19-2008, 02:38 PM
JFM626
Registered User

JFM626's Avatar
2004 TJ Wrangler

Join Date: Feb 2005
Location: Tyee Capital of Canada
Posts: 2,215
You spun a bearing. How was the crankshaft? Mark the socket 110 degrees.
JFM626 is offline
post #3 of 17 Old 12-19-2008, 03:15 PM Thread Starter
twistedgalant
Registered User

Join Date: Nov 2008
Location: Virginia
Posts: 37
crankshaft is fine. I caught it before it f'd it up. I went over everything with emery cloth. Everything is together now and torqued to 15 lbs just gotta do the 110 degrees and i can finish it. This is temporary anyways just to get me throught the winter
twistedgalant is offline
post #4 of 17 Old 12-19-2008, 04:50 PM
cmonson
Registered User

Join Date: Nov 2006
Location: Columbus
Posts: 1,546
the 110 degrees is for the bolt stretch. This means YOU HAVE TO USE NEW BOLTS... Do NOT re-use the old bolts. They are intended to stretch once. I have seen people take their chances, and it works, but I just wouldn't unless you just have to get back on the road. If you can wait, I would order a new bolt.

saying that, you can pick up a circle template with degrees marked from any art supply store. From there you torque to spec, then put your template over and mark everything with a white marker. Turn it 110 degrees and all is good.

There are actually quite a few fasteners on todays cars with degree of rotations specs. I replaced the head gasket on my saab and it was the same thing. TQ to 25#, then 130 degrees or something weird.

Great job finding the issue before you toasted the engine. Did you hear it knocking?
cmonson is offline
post #5 of 17 Old 12-19-2008, 10:24 PM
Bannonjr
Registered User
1993 ZJ

Join Date: Dec 2008
Location: St Lazare
Posts: 390
Ya...how'd you figure it? Good call by getting to it before it did more damage...

Canada Synthetics.ca
Your Friendly Canadian Amsoil Dealer!


Red Jeep Club #151
Canadian Jeeps Club Member #25
Bannonjr is offline
post #6 of 17 Old 12-21-2008, 12:29 PM Thread Starter
twistedgalant
Registered User

Join Date: Nov 2008
Location: Virginia
Posts: 37
I heard it starting to knock and pulled it apart. checked all the conecting rods for play and it was the rod closest to the firewall. Snap-on is bringing me a torque wrench tomorrow with an angle finder in it so we will see how it goes
twistedgalant is offline
post #7 of 17 Old 12-21-2008, 02:48 PM
shashank
Registered User
1999 WJ

Join Date: Aug 2006
Location: Boise,ID
Posts: 145
what engine and what model yr? How many miles were on this thing? Is there a chance that you can document this process or take pics to help others?

1999 WJ Limited
4.7 V8 Full time 4WD 134K & running All Stock
45RFE
Quadra Drive
Vari Lok's Both Front and Rear
shashank is offline
post #8 of 17 Old 12-21-2008, 03:41 PM
Bannonjr
Registered User
1993 ZJ

Join Date: Dec 2008
Location: St Lazare
Posts: 390
Quote:
Originally Posted by shashank View Post
what engine and what model yr? How many miles were on this thing? Is there a chance that you can document this process or take pics to help others?
I concur yo!

Canada Synthetics.ca
Your Friendly Canadian Amsoil Dealer!


Red Jeep Club #151
Canadian Jeeps Club Member #25
Bannonjr is offline
post #9 of 17 Old 12-21-2008, 04:15 PM Thread Starter
twistedgalant
Registered User

Join Date: Nov 2008
Location: Virginia
Posts: 37
Quote:
Originally Posted by shashank View Post
what engine and what model yr? How many miles were on this thing? Is there a chance that you can document this process or take pics to help others?
I wouldve but I'm about done with everything. I went through and replaced all the rod bearings while I was there. New oil pan gasket and sump seal, Painted the oil pan and just cleaned a bunch of stuff. All I have left to do is finish torqueing the cap bolts and put the pan on. I'll let ya know theoutcome when everything is buttoned up.


Also its a 99 WJ limited 4.7 liter 139,000 miles.
twistedgalant is offline
post #10 of 17 Old 12-21-2008, 07:01 PM
cmonson
Registered User

Join Date: Nov 2006
Location: Columbus
Posts: 1,546
curious if you did this with the engine in the car?

How much did that snap on tq wrench set you back with the degree finder? I have wanted one for a while to add to my collection.
cmonson is offline
post #11 of 17 Old 12-21-2008, 08:22 PM
crazydude2500
Registered User
1993 ZJ

Join Date: Jun 2008
Location: pa
Posts: 646
what is 110 degrees on a bolt ??? any pictures to help me understand this haha im lost

pat

green lifted 4.5 w/32's custom front bumper 5.2L
97 xj stock blue tow hooks F&R 4.0L
2004 dodge neon SRT-4
crazydude2500 is offline
post #12 of 17 Old 12-21-2008, 10:18 PM Thread Starter
twistedgalant
Registered User

Join Date: Nov 2008
Location: Virginia
Posts: 37
yes i did it with the engine in it. Only time I plan on pulling the engine is when I put my other one in. The torque wrench didnt cost me anything. lol. Im pretty tight with a few snap on guys in my area so they look out for me. Gonna let me borrow it for a day or so. I know it retails for about $500.00
twistedgalant is offline
post #13 of 17 Old 12-22-2008, 05:14 PM Thread Starter
twistedgalant
Registered User

Join Date: Nov 2008
Location: Virginia
Posts: 37
she runs awsome . Runs so quiet. Better than ever!
twistedgalant is offline
post #14 of 17 Old 12-22-2008, 05:29 PM
Virmagicus
Moderator

Virmagicus's Avatar
1998 ZJ

Join Date: Feb 2006
Location: Northern Indiana
Posts: 6,440
Quote:
Originally Posted by crazydude2500 View Post
what is 110 degrees on a bolt ??? any pictures to help me understand this haha im lost



Virmagicus is offline
post #15 of 17 Old 12-22-2008, 05:32 PM
thebgkoolio
Registered User
2013 JK Wrangler

Join Date: Feb 2007
Location: Gainesville
Posts: 246
Quote:
Originally Posted by crazydude2500 View Post
what is 110 degrees on a bolt ??? any pictures to help me understand this haha im lost
lol ok so for example of his rod caps, he had to torque it to 15 lbft. then after that the bolt as to be tightened another 110 degrees. they are torque-to-yield bolts that are for a one time use. most motors have them for rod caps, head bolts, etc. inside the motor. basically torquing it to 15 lbft tightens the bolt and then the 110 degrees stretches the bolt. thus it needing to be replaced after one use.

13 JKU -33's, afe exhaust, more to come

Sold: 94 zj -3.5" on 31's, bunch of other mods.
thebgkoolio is offline
