Go Back JeepForum.com > Models > Jeep Wrangler Forums > YJ Wrangler Technical Forum > Swap "family" style bar for "sport" style?

FS: Jeep Fog Light LED Bulbs! Several Brightness Options! ECGS Black Friday Sale!!Thanksgiving/Black Friday/Cyber Monday Deals at JeepinOutf

Reply
Unread 02-05-2009, 01:22 PM   #1
5ringleader
Registered User
1990 YJ Wrangler

Join Date: Jan 2009
Location: Sedalia CO
Posts: 8
Swap "family" style bar for "sport" style?

I have a '90 YJ, which has the sport style roll bar. Does anyone know if the later model YJ family style roll bar is a direct bolt in replacement? Are there additional seat belt mounts in the tub also, or would the 3 point belts bolt right in? The reason I am considering this is I have kids in booster seats, that require a 3 point belt.

5ringleader is offline   Reply With Quote Quick reply to this message
Unread 02-05-2009, 01:32 PM   #2
timatoe
Registered User
1990 YJ Wrangler

Join Date: Aug 2006
Location: Grass Valley California
Posts: 13,795
Some of the mounting holes may have to be opened up a bit, but it will bolt in. Upper part of the rear belts, bolt to the roll bar and the lowers go to the same current location (to the best of my knowledge). Lots of guys have done it, and I will be doing it eventually but so far just researching it.
__________________
Quote:
Originally Posted by George Orwell
We sleep safe in our beds because rough men stand ready in the night to visit violence on those who would do us harm.
timatoe is offline   Reply With Quote Quick reply to this message
Unread 02-05-2009, 06:50 PM   #3
Brandon_YJ
Registered User
1987 YJ Wrangler

Join Date: Sep 2007
Location: Metro Detroit
Posts: 3,696
This is a very common swap - I'm surprised that only one person replied to you.
You can search for "roll bar swap" or any other variation of that and find a miltitude of threads/posts on the subject, some will even contain pictures... I've seen them before.
I know some people have to open the mounting holes in the bar plates a little, but some have claimed a perfect swap with nothing but some bolt spinning required.
__________________
Quote:
Originally Posted by Mean Max View Post
I think I'll keep the YJ. But can I talk you into taking the wife?
DISCLAIMER: I (usually) browse the web using Elinks in a (text only) terminal. Which means I do not have image viewing support. So if you get confused by my seemingly inability to comment on your pictures, emoticons, etc; now you know why.
If you're still confused click here to see how I view the forum.
Brandon_YJ is offline   Reply With Quote Quick reply to this message
Unread 02-05-2009, 06:54 PM   #4
scottsjeeprolet
Registered User
1985 CJ7

Join Date: Jan 2009
Location: Kingsville, MD
Posts: 129
Direct bot in, i did it on my CJ. i added some more bars to it for safety off road.

I'm looking for one to put in my YJ.
__________________
1985 CJ-7,
1999 TJ
scottsjeeprolet is offline   Reply With Quote Quick reply to this message
Unread 02-05-2009, 08:03 PM   #5
Matt_vs_YJ
Registered User
1989 YJ Wrangler

Join Date: Jul 2007
Location: Yorktown, VA
Posts: 829
I had to enlarge 2 holes slightly, but otherwise a direct swap. Timatoe is correct, the shoulder belt and retractor attach to the new bars.
Matt_vs_YJ is offline   Reply With Quote Quick reply to this message
Unread 02-05-2009, 08:50 PM   #6
CjinPA
Web Wheeler

CjinPA's Avatar
1984 CJ7

Join Date: Mar 2006
Location: Dickson City, Pa. (North East, Pa), Pa
Posts: 1,079
You will have to drill one hole in the verticle part of each of the rear fenders to mount the fixed end of the rear seat belts shoulder strap. You might have to enlarge some of the bolt holes in the pads that mount to the floor behind the front seats. The front spreader bars might have to be adjusted by loosening the safety torx bolt in the top of them. Overall its an easy swap to do. Just try to get the male half of the rear seat belts when you buy the family style roll bar. All of the other seatbelt parts from you 90 will work with the newer roll bar.


-
__________________
84 CJ7 Northstar V8
91 YJ Renegade, I have owned it since it was new.

Jeeps that I am currently parting out;
199 Jeep TJ 4cyl 5spd
1988 Jeep YJ 6cyl 5spd
1984 Jeep CJ7 6cyl 4spd
CjinPA is offline   Reply With Quote Quick reply to this message
Unread 02-07-2009, 02:09 PM   #7
5ringleader
Registered User
1990 YJ Wrangler

Join Date: Jan 2009
Location: Sedalia CO
Posts: 8
Thanks for the info guys. I will put that on my list of things to look for at the salvage yard next time I get to go. Today would have been a good day (nice weather), but I missed their hours. Next weekend is Valentines, which might not be the smartest time to go to the salvage yard. Gotta keep the honey happy.
5ringleader is offline   Reply With Quote Quick reply to this message
Unread 02-07-2009, 02:34 PM   #8
YJames90
Registered User
1990 YJ Wrangler

Join Date: Jul 2007
Location: Dutchess County, NY
Posts: 6,928
Easy mod



I paid 75 for mine
__________________
Quote:
Originally Posted by Poke View Post
Spring Over is not for you.... yet





My 2.5 to 4.3 swap thread
http://www.jeepforum.com/forum/f12/4...begun-1237704/
YJames90 is offline   Reply With Quote Quick reply to this message
Unread 03-11-2009, 06:14 PM   #9
Augy
Registered User
1990 YJ Wrangler

Join Date: Jan 2009
Location: Iowa
Posts: 162
I just completed this swap. It was just as the others described...had to open up two holes (one in each front plate). I used a step-bit (varibit...whatever they're called) to drill a new hole and the a rotary file to finish it.

I haven't put the 3-point belt in yet but will do so this weekend. I want to find a way to secure the end to the tub in a way that would hold up in the event of a crash...I just cringe at the thought of a bolt ripping right through the tub. I'd like to take a look at a stock YJ to see how the factory did this. Anyone have a good picture?



Augy is offline   Reply With Quote Quick reply to this message
