Starter Relay or Starter Solenoid questions

Trying to reduce some wiring from a HEI upgrade... What does this green wire on the top left of the starter relay or starter solenoid do/operate? It ran into 2-4 other wires in the wiring harness that went to the distributor/alternator. It is unhooked right now and does not seem to affect anything at all.....

Attached Thumbnails
IMG_2224.JPG   IMG_2223.JPG
drespecki is offline
Sponsored Links
Advertisement

post #2 of 8 Old 02-06-2007, 11:11 AM
Big-n-Broke-YJ
BUILT. NOT BOUGHT.

Big-n-Broke-YJ's Avatar
1989 YJ Wrangler

Join Date: Apr 2005
Location: Wilmington, NC
Posts: 5,766
i can't really see it too good in those pics. it's somewhat confusing what goes where....

here's the deal from what i know... and i've dealt with that relay A LOT...

big stud goes from alternator to battery.

dark green w/white stripe goes to your starter solenoid.

black is a ground wire i think.

and the 3rd, if i remember right, is the trigger wire when you turn the key to the start position.

if you buy a new replacement from the dealer today it will have a 4th wire that if i remember right and its a ground wire.




'89 Wrangler, 4.0/AW4, 106" Wheelbase, SOA, custom XJ packs, 2" Body. Front High Pinion Dana 44 w/yukon super-joints, chromo inners and outers, and a Lincoln Locker. Rear Dana 60 w/Yukon 1.5" 35 Spline chomo shafts and detroit locker. 5.38 Yukon Gears. Hydro-Assist, 39.5x18" Boggers on 15x12 RockKrawler's w/ 2.75" of backspacing. Comp cut, tube fenders, custom bumpers and rock sliders, fuel cell, CB, Stewart Warner Gauges, SmittyBilt XRC8 Winch, 140 Amp CS-144 Alternator, Electric Fan, and a cooler of beer. 3897 lbs

March 1st, 8pm. WILMINGTON, NC MEET & GREET @ HOOTERS!
Big-n-Broke-YJ is offline
post #3 of 8 Old 02-06-2007, 11:43 AM Thread Starter
drespecki
Registered User
1983 CJ7

Join Date: Jan 2007
Location: Arizona
Posts: 1,173
Hmmm.....I have an extra tab on mine next to the big stud.. (1988 with 4.2 liter) What the h*** can it be???
drespecki is offline
post #4 of 8 Old 02-06-2007, 12:21 PM
Big-n-Broke-YJ
BUILT. NOT BOUGHT.

Big-n-Broke-YJ's Avatar
1989 YJ Wrangler

Join Date: Apr 2005
Location: Wilmington, NC
Posts: 5,766
hummmm

this is from an 89 2.5

i ASSumed they were all the same.... guess not

what kind of problem are you having?

'89 Wrangler, 4.0/AW4, 106" Wheelbase, SOA, custom XJ packs, 2" Body. Front High Pinion Dana 44 w/yukon super-joints, chromo inners and outers, and a Lincoln Locker. Rear Dana 60 w/Yukon 1.5" 35 Spline chomo shafts and detroit locker. 5.38 Yukon Gears. Hydro-Assist, 39.5x18" Boggers on 15x12 RockKrawler's w/ 2.75" of backspacing. Comp cut, tube fenders, custom bumpers and rock sliders, fuel cell, CB, Stewart Warner Gauges, SmittyBilt XRC8 Winch, 140 Amp CS-144 Alternator, Electric Fan, and a cooler of beer. 3897 lbs

March 1st, 8pm. WILMINGTON, NC MEET & GREET @ HOOTERS!
Big-n-Broke-YJ is offline
post #5 of 8 Old 02-06-2007, 01:14 PM
atomicmoose
Just call me Moose

atomicmoose's Avatar

Join Date: Nov 2004
Location: South Jersey
Posts: 3,970
Quote:
Originally Posted by drespecki
Hmmm.....I have an extra tab on mine next to the big stud.. (1988 with 4.2 liter) What the h*** can it be???
Mine has the extra stub as well. Can't remember where it goes ATM... I can check later.
atomicmoose is offline
post #6 of 8 Old 02-06-2007, 04:08 PM Thread Starter
drespecki
Registered User
1983 CJ7

Join Date: Jan 2007
Location: Arizona
Posts: 1,173
Just wondering if this wire/connection goes to something critical... I did the 2100/HEI upgrades and have a few scraps to clean up...
drespecki is offline
post #7 of 8 Old 02-06-2007, 04:29 PM
Big-n-Broke-YJ
BUILT. NOT BOUGHT.

Big-n-Broke-YJ's Avatar
1989 YJ Wrangler

Join Date: Apr 2005
Location: Wilmington, NC
Posts: 5,766
it's your starter relay, but it's not THAT important...
I mean, you could always push start your jeep, assuming it's a manual.....

'89 Wrangler, 4.0/AW4, 106" Wheelbase, SOA, custom XJ packs, 2" Body. Front High Pinion Dana 44 w/yukon super-joints, chromo inners and outers, and a Lincoln Locker. Rear Dana 60 w/Yukon 1.5" 35 Spline chomo shafts and detroit locker. 5.38 Yukon Gears. Hydro-Assist, 39.5x18" Boggers on 15x12 RockKrawler's w/ 2.75" of backspacing. Comp cut, tube fenders, custom bumpers and rock sliders, fuel cell, CB, Stewart Warner Gauges, SmittyBilt XRC8 Winch, 140 Amp CS-144 Alternator, Electric Fan, and a cooler of beer. 3897 lbs

March 1st, 8pm. WILMINGTON, NC MEET & GREET @ HOOTERS!
Big-n-Broke-YJ is offline
post #8 of 8 Old 01-22-2010, 09:33 AM
GrandJoker
Registered User
2009 JK Wrangler

Join Date: Jul 2009
Location: Mount Olive
Posts: 72
yea mine had the extra stub on it to but the new one i have only has three an the big stud WTH.
GrandJoker is offline
