springs, axles, and swapping?

Hey everybody, i have a yj and i see that people swap out xj leaf's onto their yj. i was wondering if thier a direct swap and what kinda lift do they give. also ive been looking around at axles, i want to do a 350 swap and run 37-40 tires, and i found rockwells for around 500 bucks per 2.5 ton axle. which brings me to my next question why dont you see any under jeeps? and finaly where would i find the 231c, i think it is, to bolt up to the chevy trans? thanks a lot guys

jmathis3 is offline   Reply With Quote Quick reply to this message
Unread 02-13-2008, 12:15 PM   #2
Michael_94YJ
Registered User
1994 YJ Wrangler

Join Date: Mar 2007
Location: Savannah, GA
Posts: 768
xj leafs are a little longer than yj springs and give about 2" lift IIRC.
I believe the main downfall to rockwells are:
pinion brakes
6.72 gears (no other choices that i know of)
weight
center section usually gets shaved
different bolt pattern
and probably a few other things to add. Not saying it's not a good choice just giving you possible reasons.
Can't help you with the t-case sorry
__________________
1994 YJ 4.0L 5 spd.
flowmaster,15x12 wheels & 35x15 TSLs, sway bar discos, 3.5" leaves SOA + shackles, 2" body lift, JB steering bracket, SYE, M.O.R.E. anti-wrap bar, Bilsteins 5125s up front & BDS Hydros out back, axles in the works
http://i178.photobucket.com/albums/w...y/Image075.jpg
Michael_94YJ is offline   Reply With Quote Quick reply to this message
Unread 02-13-2008, 12:41 PM   #3
Tulsachokehold
Registered User
1991 YJ Wrangler

Join Date: Mar 2006
Location: Tulsa OK
Posts: 697
you cant drive on the street with a pinion brake in most states. Unless you do the disc brake conversion on a Rockwell, (wich cost about $1500 per axle) you are pretty much making your Jeep a trail only rig.
Tulsachokehold is offline   Reply With Quote Quick reply to this message
Unread 02-13-2008, 12:46 PM   #4
TnTRacing28
Registered User
1991 YJ Wrangler

Join Date: Feb 2007
Location: SW Florida
Posts: 369
Quite a few jeep here in florida run them, but they are all mud only jeeps.
__________________
/l ,[____],
l---L 0lllllll0-
()_) ()_)--o-)_)
War doesn't decide who's Right? Only who's Left!
TnTRacing28 is offline   Reply With Quote Quick reply to this message
Unread 02-13-2008, 12:53 PM   #5
Tulsachokehold
Registered User
1991 YJ Wrangler

Join Date: Mar 2006
Location: Tulsa OK
Posts: 697
Quote:
Originally Posted by TnTRacing28 View Post
Quite a few jeep here in florida run them, but they are all mud only jeeps.

Rockwells are all over the place here, but they are trailer queen rock crawlers that ride on 44"+ tires and usualy have a healthy v8 and run a minimum of 4:1 geared D300's or Stak or Atlass Tcase or something of the like.. Also, most of the guys who wheel them, use 2 steering axles.

Tulsachokehold is offline   Reply With Quote Quick reply to this message
Unread 02-14-2008, 10:32 AM   #6
jmathis3
Registered User
1993 YJ Wrangler

Join Date: Feb 2008
Location: akron
Posts: 18
awsome guys. that helps a lot. no one has any reply on where to get the
231c for the 350 swap? and whats the difference betweet the two transfer cases
jmathis3 is offline   Reply With Quote Quick reply to this message
Unread 02-14-2008, 11:26 AM   #7
Tulsachokehold
Registered User
1991 YJ Wrangler

Join Date: Mar 2006
Location: Tulsa OK
Posts: 697
TH350 trans or Small Block Chevy 350 CID engine?

If you are looking for a TH350 trans to a NP231 adapter... check with Advanced adapters or Novac Conversion.
Tulsachokehold is offline   Reply With Quote Quick reply to this message
Unread 02-14-2008, 11:31 AM   #8
leftlanetruckin
XJ on 37's

leftlanetruckin's Avatar
1998 XJ Cherokee

Join Date: Jul 2006
Location: missouri via blackpool,lancs.
Posts: 10,606
the 231 c came behind the 700r4's in s10 blazers and the like.
i dont think they came behind any other tranny (350,400 etc), so it would be counter productive to use in that case. different output shaft on the tranny i believe.
get the t/case that came behind it, and then you could maybe run a passenger side drop front axle (dana 60), which are cheaper than a driver side drop due to everyone wanting them for the jeeps they own......like me!

martin
__________________
1998 XJ on 37's.JK Rubi axles with chromo shafts and ctm's, 4:1 transfer case, etc etc etc.The Cherylkee....
2003 Range Rover HSE, 4.4 Quad Cam.
1998 Range Rover 4.6 HSE
2000 4.7 4WD WJ with a rebuilt motor.
4.3/700r4/new frame buildup (YJ)....
http://www.jeepforum.com/forum/f12/swap-offically-underway-324622/

Years to gain the hands on experience, and offer it freely.
Minutes to gain the knowledge from the internet, and quote it just as freely.
Choose wisely!
leftlanetruckin is offline   Reply With Quote Quick reply to this message
Unread 02-14-2008, 11:35 AM   #9
NewGuyYJ
Registered User
1987 YJ Wrangler

Join Date: Apr 2007
Location: Michigan
Posts: 26
I'm looking for the 231c as well, and according to everything I've read (which could be wrong, you never know) the right case to get is behind the auto v6 chevy s-10 4x4 from 88 - 92 (?). Snag the tranny too, its a 700r4. If I'm wrong, someone else can correct me.
__________________
1987 YJ 4.2l crappy BA 10/5 stock
NewGuyYJ is offline   Reply With Quote Quick reply to this message
