soa ideas?

so i bent a leave spring today i have the rustys 4inch with 1 1/4 shackels. so icalled rustys and they want me to ship it back to them. so im thinking about doing soa. im buying a sye kit and doing the ford explorer front shaft. i have a brand new set of stock leaves. i only thing im unsure about is the steering i just bought the rustys steering so thats new. so need some helpp

bigred94 is offline
Sponsored Links
Advertisement

post #2 of 13 Old 04-07-2010, 04:20 PM
highrolrcustoms
Registered User
1995 YJ Wrangler

Join Date: Jan 2010
Location: Johnson City Tennessee
Posts: 386
i am using the jb4x4 bracket with stock pitman arm but have terrible bump steer. i have a drop pitman arm i am going to add...hopefully that will help some but i am sure with your set up the jb4x4 bracket will do the job just fine!!

95 yj juggy, backhalfed, 3 link front with 16" fox dual rate remote resi coilovers, 4 link rear with 16" fox air shocks, Monster Stak 2 Speed transfer case 4.33:1, full width ford 78/79 dana 60hp front axle with 538 gears and full spool, ford sterling 10.25 full width rear axle with 538 gears welded and disc brake conversion, 42x15 swamper tsl's on 15x8 Allied wheels 3.5" backspacing with DIY beadlocks, High Steer with 1.5x.250 dom tubing, Full Hydro steering, custom cage, rci 2161a fuel cell ,smitty xrc 8 winch, cv driveshaft, jk motor mount lift, racing seats with simpson 5 point harnesses

http://www.jeepforum.com/forum/f12/3...begun-1108933/


"THE MORE YA PLAY WITH IT.....THE BIGGER IT GETS"
highrolrcustoms is offline
post #3 of 13 Old 04-07-2010, 05:01 PM Thread Starter
bigred94
Registered User
1994 YJ Wrangler

Join Date: Nov 2009
Location: rhode island
Posts: 134
I'm gonna run stock springs and ihave a droped pitman arm and a transfer vase lowering kit so I just realy need steering ideas.
bigred94 is offline
post #4 of 13 Old 04-07-2010, 06:17 PM
jeepinmichguy_
Registered User
2003 TJ Wrangler

Join Date: Jul 2009
Location: The Sticks
Posts: 7,381
rocky road ott steering for me.

ΜΟΛΩΝ ΛΑΒΕ

Quote:
Originally Posted by TheBoogieman View Post
Jeepinmichguy is a jerk.
Quote:
Originally Posted by mrblaine View Post
How about this, if you had the Jeep Spirit, you wouldn't abuse the rest of us trying to enjoy a nice day out wheeling by bringing your brokeass broken down junkyard crap out to play where it can't handle it?
Quote:
Originally Posted by JeepForum123 View Post
you all have nice rigs, stop being f****** a**holes.
jeepinmichguy_ is offline
post #5 of 13 Old 04-07-2010, 06:29 PM
RockWoRM
LJ's do it longer

RockWoRM's Avatar
2005 LJ Wrangler

Join Date: Mar 2006
Location: Fresno
Posts: 9,235
There is a little more to SOAs than just flipping the springs. To do it right, as far as what most would consider 'right', you'll likely need a trac bar in the rear to prevent axle wrap... and crossover steering tends to be the prefered system. All this takes a little more $$$, but it all depends on what you want in the end.




WRM

'05 LJR, 6sp, RC long arm w/MC 6" coils, 5.13 D44's w/chromo shafts, MetalCloak fenders/sliders/body armor, 37x12.50 MTR's, Warn 9.5, RockHard swing out w/full spare. <><
RockWoRM is offline
post #6 of 13 Old 04-07-2010, 07:39 PM
YJames90
Registered User

YJames90's Avatar
2012 JK Wrangler

Join Date: Jul 2007
Location: Dutchess County, NY
Posts: 6,979
Quote:
Originally Posted by bigred94 View Post
I'm gonna run stock springs and ihave a droped pitman arm and a transfer vase lowering kit so I just realy need steering ideas.
And,,,,,,,,,,,,
shock mounts
shocks
extended brake lines
extended front DS
extended drag link
double cv DS for the rear
new spring perches
SYE, installed or DIY
bigger tires
close to $1000.00
lots of time if you are doing it yourself

Quote:
Originally Posted by Poke View Post
Spring Over is not for you.... yet





My 2.5 to 4.3 swap thread
http://www.jeepforum.com/forum/f12/4...begun-1237704/
YJames90 is offline
post #7 of 13 Old 04-07-2010, 08:30 PM Thread Starter
bigred94
Registered User
1994 YJ Wrangler

Join Date: Nov 2009
Location: rhode island
Posts: 134
the only real thing i need as of now is sye and driveshafts spring perchs are noting. shocks i have preety long shocks as of now there for 7inchs of lift. and the track bar you mean 5th link right? i was looking at these pieces you put on the spindels so you can flip the tie rod ends.i havent realy heard alot about them.
bigred94 is offline
post #8 of 13 Old 04-07-2010, 09:17 PM
Sidewinder
Registered User
1994 YJ Wrangler

Join Date: Feb 2009
Location: Dacula, Georgia
Posts: 913
you can get a cherokee ds and have it shortened for the rear ds. its pretty good and 15 bucks at junkyards

Jethro Build
ASK ME ABOUT SIXDITCH
Sidewinder is offline
post #9 of 13 Old 04-07-2010, 09:24 PM Thread Starter
bigred94
Registered User
1994 YJ Wrangler

Join Date: Nov 2009
Location: rhode island
Posts: 134
i was thinking the ford one ive already have an 8.8 so it would be the same univeseals
bigred94 is offline
post #10 of 13 Old 04-07-2010, 09:27 PM
wrangler76
Registered User
1995 YJ Wrangler

Join Date: Sep 2009
Location: Carson, WA
Posts: 412
I ran my SOA for a while with stock springs and an add-a-leaf with the stock steering setup plus the drop pitman but dropped the dampener. You can grind off the stock shock mounts and reweld them on pretty easily. I was running 35's with 3.07 gears in the open d30/35s and didn't need a traction bar because it was so long legged. I went full high steer when I went with 3.5" lift springs and built a D44 front for the beast this winter. I was SUA for alot of years then went SOA and have never looked down.... errr back. Good luck and post some good pictures!
wrangler76 is offline
post #11 of 13 Old 04-07-2010, 09:37 PM
Fhajad
Registered User
1993 YJ Wrangler

Join Date: Jun 2009
Location: Greenfield
Posts: 1,932
Quote:
Originally Posted by bigred94 View Post
and the track bar you mean 5th link right?
Around here, it's sway and track bars. Never heard anyone call it 5th link.
Fhajad is offline
post #12 of 13 Old 04-08-2010, 09:55 AM
wrangler76
Registered User
1995 YJ Wrangler

Join Date: Sep 2009
Location: Carson, WA
Posts: 412
Sway Bars, Track Bars, Traction Bars aka Antiwrap Bars are three seperate devices affecting 3 different axle planes of travel. A 5th link I imagine is another name for a traction bar....
wrangler76 is offline
post #13 of 13 Old 04-08-2010, 09:57 PM Thread Starter
bigred94
Registered User
1994 YJ Wrangler

Join Date: Nov 2009
Location: rhode island
Posts: 134
yes it is... but you can run the stock steering with a dropped pitman arm? did you have bump steer at all? this is the only thing that worrys me right now i bought the rustys steering setup in feb it was 250 so i dont realy wanna get rid of it yet. and how bout the track and sway bars i dont have them any more?
bigred94 is offline
