This plug does THIS

Over the years I've seen a number of posts asking "what does this unplugged harness go to?" Well, while I was rummaging through my FSM today looking for something, I stumbled across the following diagrams and went HOLY S**T!!! Another FSM nirvana moment


Inside cab wiring harness connector identification:



Under hood wiring harness connector identification:



__________________
1996 White ZJ
1987 Maroon YJ (sideways build)
1996 Forest Green XJ

The "sideways" build thread: http://www.jeepforum.com/forum/f22/r...hread-2164793/
