Unread 12-14-2008, 01:38 PM   #1
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
Need Help Ignition Switch !!!!!



Ok guys New problem has arisen. Thanks to everyone here i recently repair my dont start problem previosuly posted under cranks and cranks etc......

welll after I fixed that problem i ran into another problem. My ignition switch, Not to be confused with the ignitionLock which of course the key goes into.

Im referring to the ignition switch ontop of the steering column, that utlizies an actuator rod to start the car.

I reached in their to inspect it, clean it make sure everything was good to go, and I moved it I disengaged the rod and cant seem to figure out what im doing wrong. I cant seem to put her back on. Im completely confused.

This is a simple mechanical jigsaw puzzle that i cant not seem to solve. mind you the weather is getting colder and it certianly isnt helping my patience any...Ugghhh and I just solved one other problem with the ECM.


HELPPPPPPPPp

crzylgzz is offline   Reply With Quote
Unread 12-14-2008, 03:44 PM   #2
SniperYJ
Registered User
1992 YJ Wrangler

Join Date: Aug 2008
Location: Columbus, GA
Posts: 81
If you took it completely out, then it will take a little adjusting to get it back in correctly.
To do it, ensure the notch on the switch is in the Accessories position, and make sure your key is also in this position when you try to put it back on. Once that is done, position the switch on the rod and get the bolts started. Before tightening them all the way down, pull the switch assembly as far toward the front of the vehicle as you can, then tighten the bolts down and try it out. If your key is still not making the Jeep do what it should be doing, then you are going to have to find the "sweet spot" for your Jeep. I have this issue with my 92and my buddies 87, but they were both pretty easy to fix, once I got an idea what the issue was. Hope this helps
SniperYJ is offline   Reply With Quote
Unread 12-14-2008, 04:03 PM   #3
laybackman
Bikini Bridge Inspector

laybackman's Avatar
1995 YJ Wrangler

Join Date: Dec 2002
Location: Massachusetts
Posts: 6,084
Quote:
Originally Posted by crzylgzz View Post


Ok guys New problem has arisen. Thanks to everyone here i recently repair my dont start problem previosuly posted under cranks and cranks etc......

welll after I fixed that problem i ran into another problem. My ignition switch, Not to be confused with the ignitionLock which of course the key goes into.

Im referring to the ignition switch ontop of the steering column, that utlizies an actuator rod to start the car.

I reached in their to inspect it, clean it make sure everything was good to go, and I moved it I disengaged the rod and cant seem to figure out what im doing wrong. I cant seem to put her back on. Im completely confused.

This is a simple mechanical jigsaw puzzle that i cant not seem to solve. mind you the weather is getting colder and it certianly isnt helping my patience any...Ugghhh and I just solved one other problem with the ECM.


HELPPPPPPPPp
Here is some links topics from a '95 FSM. Did it this way since the poics are large. This may help you with the parts in front of you. I'll leave these pics up for a whiule OK?

http://home.comcast.net/~laybackman/x60.jpg

http://home.comcast.net/~laybackman/x61.jpg

http://home.comcast.net/~laybackman/x62.jpg

http://home.comcast.net/~laybackman/x63.jpg

http://home.comcast.net/~laybackman/x64.jpg

http://home.comcast.net/~laybackman/x65.jpg
__________________
Chicks dig me.....Fish fear me

Getting older, I have developed some special skills. I have the ability to cough, sneeze, fart and pee at the same time.

"If we cannot afford to take care of Veterans, then we should stop making them."
David C. Wilker Jr. USAF (RET)
laybackman is offline   Reply With Quote
Unread 12-14-2008, 06:01 PM   #4
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
Layback, that post was extremely helpful, but unortunately my problem isnt the IGNITION LOCk. , but rather the ignition swith, that hidden doo hickey on the steering column itself. I got it off, , but for some reason she doesnt wanna go back on.

I dont wish to apply pressure to the rod for fear of damaging it. But
walk me thru this

1. the rod attaches to the ignition switch on the side of the actual switch, I see a hole there for what appears to be the opening forthe rod.

2. I place the rod in, seat the switch apply bolts, adjust for operation, and then thats it.

So i attach the bolt. and then i cant get the switch to seat on its bolt seat. its insane. its as if the assembly never belonged there .

my switch looks like this, only blue. suggestions.

crzylgzz is offline   Reply With Quote
Unread 12-14-2008, 06:03 PM   #5
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
[QUOTE=SniperYJ;6174817].
To do it, ensure the notch on the switch is in the Accessories position, and make sure your key is also in this /QUOTE]


Ok the Key part I can do, but i dont fully know where or what position accessory is on the actual switch, therearent any indicators for such.
crzylgzz is offline   Reply With Quote
Unread 12-14-2008, 06:04 PM   #6
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
Hey,,, if i can repair my ECM, I can do this. I just dont wanna damage anything, Hence why im asking.
crzylgzz is offline   Reply With Quote
Unread 12-14-2008, 06:08 PM   #7
bmxer0122
Registered User
1987 YJ Wrangler

Join Date: Jul 2008
Location: jackson NJ
Posts: 424
that is the correct peice for the non tilt steering column type. so first check that. i just installed the same peice today the trick is to look at how the origional was set up and take a small screw driver and set it up to look exactly the same. when you try to seat it do not put the plugs in first, put htem in after it is secure.
1-First put that crazy screw in that has the washer and hex head attached to the shaft
2- line up the white and silver peice that has a black plug( on the left side of the column, uses same screws to hold down)
3- then put the little hex headed screw in that is closest towards the steering column
4- secure the farther end by putting the hex nut on and tighten down
5. now re-plug the plugs into place

that is how i did it and i had no isues w/ reconnecting it
bmxer0122 is offline   Reply With Quote
Unread 12-15-2008, 03:22 AM   #8
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
Hey BMX Morning, never mind the time stamp on this board. Trust me when I tell you that its 0500 hrs our time and this has me going insane.

OK your explanation is doable. Ill do it.

But if you can remember, the position of the Rod that would be a great help. My rob when your looking at it bends upwards. The hole within the switch seems to force the rod onto its side causeing a tension when you attenpt to insert it.

Now my question is, do i bend the rod to fit or shoild it just pop in " no fuss no muss"
crzylgzz is offline   Reply With Quote
Unread 12-15-2008, 07:11 AM   #9
laybackman
Bikini Bridge Inspector

laybackman's Avatar
1995 YJ Wrangler

Join Date: Dec 2002
Location: Massachusetts
Posts: 6,084
Quote:
Originally Posted by crzylgzz View Post
Hey BMX Morning, never mind the time stamp on this board. Trust me when I tell you that its 0500 hrs our time and this has me going insane.

OK your explanation is doable. Ill do it.

But if you can remember, the position of the Rod that would be a great help. My rob when your looking at it bends upwards. The hole within the switch seems to force the rod onto its side causeing a tension when you attenpt to insert it.

Now my question is, do i bend the rod to fit or shoild it just pop in " no fuss no muss"
I would not be bending any rods as there is an adjustment hole for the switch. I haven't had a column apart in some years but with other prople chiming in here I beleive you will get it in eventually. Question - Do you have a tilt or non-tilt column and would it make a difference. It must I would think.
__________________
Chicks dig me.....Fish fear me

Getting older, I have developed some special skills. I have the ability to cough, sneeze, fart and pee at the same time.

"If we cannot afford to take care of Veterans, then we should stop making them."
David C. Wilker Jr. USAF (RET)
laybackman is offline   Reply With Quote
Unread 12-15-2008, 07:14 AM   #10
laybackman
Bikini Bridge Inspector

laybackman's Avatar
1995 YJ Wrangler

Join Date: Dec 2002
Location: Massachusetts
Posts: 6,084
And both ends of that rod are shown in this picture but not in great detail.
http://home.comcast.net/~laybackman/x62.jpg
__________________
Chicks dig me.....Fish fear me

Getting older, I have developed some special skills. I have the ability to cough, sneeze, fart and pee at the same time.

"If we cannot afford to take care of Veterans, then we should stop making them."
David C. Wilker Jr. USAF (RET)
laybackman is offline   Reply With Quote
Unread 12-15-2008, 08:02 AM   #11
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
All i can say is WOW. I mean really, wow. when I accidentally removed my switch, I didnt notice the position of the actual switch itself. The whole time i had the piece not only reversed, but upside down. I mean what kind of a simpleton am I.

I looked at my friends 95 Jeep. and I discovered the problem.

BMX, Layback, SNIPER, you guys are ACES, thnxs so much for your Input, Support and guidance.

I fell in love with the forum, Ill be here lending my experience, and what will become "Know how" to all that ask.

Again, thank you.

Needless to say i got it in, Needs some adjusting, but she's in and she starts up.

Mark this the 2nd item I conquered on this forum...

Issue RESOLVED.
crzylgzz is offline   Reply With Quote
Unread 12-15-2008, 08:23 AM   #12
wildman90
Registered User
1993 YJ Wrangler

Join Date: Oct 2008
Location: st louis
Posts: 201
and another one bites the dust! glad its fixed
wildman90 is offline   Reply With Quote
Unread 12-15-2008, 02:40 PM   #13
crzylgzz
Registered User
2011 JK Wrangler

Join Date: Dec 2008
Location: NYC, NY
Posts: 276
I feel like acomplete fool, I didnt even realize I had it not only reversed, but upside down as well.
After it was installed ......
crzylgzz is offline   Reply With Quote
Unread 12-15-2008, 06:14 PM   #14
SniperYJ
Registered User
1992 YJ Wrangler

Join Date: Aug 2008
Location: Columbus, GA
Posts: 81
Glad to hear we could help
SniperYJ is offline   Reply With Quote
Unread 12-31-2008, 03:45 PM   #15
RSLary
Registered User
2002 TJ Wrangler

Join Date: Jan 2008
Location: Maine
Posts: 31
I could use a bit of advise on ignition switch. When I put the key in and try to turn on, I have to jiggle it around a bit to get it to turn. Its a given that somtime soon it wont turn at all. Can someone tell me where to start with this problem? I replaced the directional control arm last year (with the help of this forum, THANK YOU) how does that repair compare to this one on the challange meter?
RSLary is offline   Reply With Quote
