Help With Ford 9", or Ford 8.8

Hey guys, I have three Early Ford Broncos with the short 9" rear ends, and I was wondering just how easily these rear ends will bolt in. I know they have drum brakes, but I'm sure I can find a conversion kit for a reasonable price, or do something myself. I also have a cousin who owns a massive salvage yard, so I have access to a plethora of Ford 8.8 rear ends. I was just wanting feedback on whether the Ford 9" is substantially stronger over the 8.8, or if I should just go with a 8.8 and save myself some headache if there is anymore involved with installing a 9" over a 8.8. Also, is the bolt pattern the same? I can't get home to measure it for a while. Thanks so much guys and any feedback is welcome.

Cbaughn is offline   Reply With Quote Quick reply to this message
Unread 10-27-2008, 01:33 PM   #2
KennyTJ
Registered User
2006 TJ Wrangler

Join Date: May 2007
Location: Maineville, Ohio
Posts: 683
9" is awsome strong with 33 or 35 spline axles. Not sure if the bronco came with more than 30 spline though. Not sure about the bolt patern but it's either 5on5.5 or 5on4.5. It's worth looking into.
__________________
Silver '06 TJ w/ neat stuff on her!
"New" 1987 YJ Project for my son!
KennyTJ is offline   Reply With Quote Quick reply to this message
Unread 10-27-2008, 01:34 PM   #3
MLJeeper
Registered User
1988 YJ Wrangler

Join Date: Nov 2004
Location: Birmingham, Al.
Posts: 5,029
The swap in is as simple as doing the 8.8 swap. You can use the same bracket kits they sell for the 8.8. The early bronco axles are a bit shorter than even the 8.8 axles. The lug pattern will be 5 on 5.5 but can be converted with a set of spacers that make the width just right. As for strength, after market and the plethora of second hand parts, the 9" gets the nod. Go with the big bearing housing. If its not 31 spline thats easy to remedy but getting shafts for 31 spline with the small bearing is pretty much impossible. Even on the custom front.

Depending on your goals, 28 spline is still not a bad upgrade but make sure you have the option to upgrade to 31 splines etc by going with the big bearing housing. Course you can weld big bearing ends on the housing. Ahh the 9" ford, endless possibilities.
__________________
Your limited slip differential sucks.

Quote:
Originally Posted by Anticanman View Post
Any video of the sound?

Last edited by MLJeeper; 10-27-2008 at 01:45 PM..
MLJeeper is offline   Reply With Quote Quick reply to this message
Unread 10-27-2008, 01:51 PM   #4
Cbaughn
Registered User
1994 YJ Wrangler

Join Date: May 2008
Location: Birmingham, AL
Posts: 277
Ha, that is awesome to hear then. I will probably beef her up pretty nicely and throw it in. I like the idea of using a spacer with a different bolt pattern to get back my width and use my wheels. I think it is 5x5.5 on the Broncos rear. I have a 4" rough country on it now, and if I spring-over the rear and put back on the stock leaf springs will the back match the front as far as heighth? I just think it would be easier to just do the back if it would sit right and do the front at a later date maybe. Any feedback is very welcome.
Cbaughn is offline   Reply With Quote Quick reply to this message
Unread 10-27-2008, 02:18 PM   #5
MLJeeper
Registered User
1988 YJ Wrangler

Join Date: Nov 2004
Location: Birmingham, Al.
Posts: 5,029
I upgraded my dif when i went with more lift. My rig sits level with the early bronco axle in it SUA. NOt sure with your proposed config.

I wouldn't say i like the idea of running the spacers, but they've certainly caused me no issues and i beat my rig hard. When you go to install, you will either have to grind down the wheel studs to clear the spacers or get shorter studs. I will try to find the napa part number for the shorter studs.
__________________
Your limited slip differential sucks.

Quote:
Originally Posted by Anticanman View Post
Any video of the sound?
MLJeeper is offline   Reply With Quote Quick reply to this message
Unread 10-27-2008, 02:22 PM   #6
Cbaughn
Registered User
1994 YJ Wrangler

Join Date: May 2008
Location: Birmingham, AL
Posts: 277
I was just wondering if with a 4" Rough Country in the front and stock springs spring over in the rear if the rig would sit level. And the ideas of spacers don't bother me, and I would very much appreciate that part number.
Cbaughn is offline   Reply With Quote Quick reply to this message
Unread 10-29-2008, 12:37 PM   #7
Cbaughn
Registered User
1994 YJ Wrangler

Join Date: May 2008
Location: Birmingham, AL
Posts: 277
Anybody know if she would sit level with that configuration? 4" Rough Country springs in the front and Spring-Over in the rear?
Cbaughn is offline   Reply With Quote Quick reply to this message
Unread 10-29-2008, 12:45 PM   #8
sbenja2003
Registered User
2005 WK

Join Date: Jun 2008
Location: Post Falls, Id
Posts: 68
Ive heard that a soa with stock springs = 5.5 of lift so it would probably sit higher in the back.
sbenja2003 is offline   Reply With Quote Quick reply to this message
Unread 10-29-2008, 01:15 PM   #9
Mobile_Homie
Desert Rat

Mobile_Homie's Avatar
1994 YJ Wrangler

Join Date: Jun 2008
Location: Winnemucca, NV
Posts: 1,288
Quote:
Originally Posted by MLJeeper View Post
The swap in is as simple as doing the 8.8 swap. You can use the same bracket kits they sell for the 8.8. The early bronco axles are a bit shorter than even the 8.8 axles. The lug pattern will be 5 on 5.5 but can be converted with a set of spacers that make the width just right. As for strength, after market and the plethora of second hand parts, the 9" gets the nod. Go with the big bearing housing. If its not 31 spline thats easy to remedy but getting shafts for 31 spline with the small bearing is pretty much impossible. Even on the custom front.

Depending on your goals, 28 spline is still not a bad upgrade but make sure you have the option to upgrade to 31 splines etc by going with the big bearing housing. Course you can weld big bearing ends on the housing. Ahh the 9" ford, endless possibilities.
Ford 9" in this car
__________________
Mark



Smoke em if you got em!

Click here
Mobile_Homie is offline   Reply With Quote Quick reply to this message
Unread 10-29-2008, 01:27 PM   #10
rescueyj
Registered User

Join Date: Apr 2006
Location: MD/VA
Posts: 210
What is the benifit of just springing over the rear
__________________
Wheeler-87 yj project built 4.2, custom suspension, front and rear bumpers with stinger,8000lb winch,striped interior, 33in mtr's, Future-8.8 rear, 4.88 gears locked front and rear
Tow Rig- 02 F150 on 35's sum engine stuff and a old trailer http://militarysignatures.com/signat...ember10866.png
rescueyj is offline   Reply With Quote Quick reply to this message
Unread 10-29-2008, 05:39 PM   #11
Cbaughn
Registered User
1994 YJ Wrangler

Join Date: May 2008
Location: Birmingham, AL
Posts: 277
That way I just have it done, and when i decide to do the front, I will just have to do that. And isn't the axle is already spring-over, I just don't know if the perches are the correct width apart. You feel me? Ha.
