Go Back JeepForum.com > Models > Jeep Wrangler Forums > YJ Wrangler Technical Forum > Broke my Leaf Spring.. Is this a good replacement???

Year End Clearance Sale! Save 20%Introducing MONSTALINER™ UV Permanent DIY Roll On Bed LineNEW!! HMF 50"-52" light bar mounting brackets!!

Reply
Unread 04-04-2010, 11:42 PM   #1
Bridges31
Registered User
1987 YJ Wrangler

Join Date: Jan 2009
Location: NH
Posts: 50
Broke my Leaf Spring... FOLLOW UP Question: Post #12

I asked a follow up question on post #12

Just looking for some advice here. First wheeling trip of the season left me with no jeep as I ended up hitting a rock or something with my shackle, causing the driver's side leaf spring to break in half. The mud was good though and I ended up not being able to see out of my windows when I was done

All four leaf springs on the jeep are old anyways. They are all straight with no bend left to them at all. Unfortunately, money is a little tight right now and I can't buy a lift kit so I just have to buy the springs.

My question is, what does everyone think about these? They seem like a decent price Old Man Emu CS014F - Old Man Emu 2.5&...YJ - Quadratec

Also, since im trying to save money, how lop-sided will my jeep look if I replace just the front two springs for now (the back one's are worn out with no bend)? Thanks.

I should add, everything is pretty much stock on the jeep with the exception of a little bit longer shackles and 31" tires.

Thanks!


Last edited by Bridges31; 04-13-2010 at 09:21 AM..
Bridges31 is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 12:22 AM   #2
Barrio
Registered User
1992 YJ Wrangler

Join Date: Oct 2007
Location: Pittsburgh, Pa
Posts: 3,698
If moneys tight look into Rough County.

roughcountry.com
__________________
www.offroadjunkies.net
www.pgh-offroad.com
-OD Green/Flat Black 92' 4" Rough Country Lift, tons of crap.
-Rio Red 1995 Ford Mustang- Daily Driver
Quote:
Originally Posted by alfmoney
i see theres a bunch of toughguys on this forum or internet gangstas
Barrio is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 12:22 AM   #3
moonshinefuel
Registered User
1995 YJ Wrangler

Join Date: Feb 2009
Location: Los Angeles. California. United States.
Posts: 4,911
Emu is a good spring, so is rubicon, bds. The emu leafs require emu bushings, which are expensive, unless you are lucky and have bushings of your own that will fit.
moonshinefuel is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 05:26 AM   #4
jeep795
Registered User
1992 YJ Wrangler

Join Date: Jun 2005
Location: warren, ma
Posts: 1,024
I think it'd look pretty weird with a 2.5 lift in front and nothing in the back. I broke a few springs here and there and always found a used spring from a friend or online for cheap or free to replace it with, then when money permitted bought all 4 at once.
__________________
"my jeep is pretty much my wife. it gets most of my time, and it loves when i spend money on it."
jeep795 is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 09:39 AM   #5
Bridges31
Registered User
1987 YJ Wrangler

Join Date: Jan 2009
Location: NH
Posts: 50
Quote:
Originally Posted by jeep795 View Post
I think it'd look pretty weird with a 2.5 lift in front and nothing in the back. I broke a few springs here and there and always found a used spring from a friend or online for cheap or free to replace it with, then when money permitted bought all 4 at once.
I've been looking on craigslist and asking friends but no luck with any cheap springs. Does anyone know if leafs from any another vehicle will fit the YJ?
Bridges31 is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 09:43 AM   #6
Mudtracker
Registered User
1987 YJ Wrangler

Join Date: Jun 2009
Location: Ma
Posts: 51
Quote:
Originally Posted by moonshinefuel View Post
The emu leafs require emu bushings
Is this documented somewhere? I used the energy suspension bushings from Q-tec and they seem to work just fine. I've only had them on for a few weeks though.
Mudtracker is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 10:21 AM   #7
RockWoRM
Web Wheeler

RockWoRM's Avatar
1992 YJ Wrangler

Join Date: Mar 2006
Location: Fresno, Ca.
Posts: 8,585
Quote:
Originally Posted by Bridges31 View Post
I've been looking on craigslist and asking friends but no luck with any cheap springs. Does anyone know if leafs from any another vehicle will fit the YJ?
There are lots of springs that you could 'make work', but IMO I'd rather go with something specifically made for a YJ. I 'believe' waggy springs will work, but IIRC they are a little long. I know a few guys around here that love to mix and match springs and make them work, but IMO it is more of a guessing game. But if thats what you want to do then you'd just need to get the eye to eye measurements, coupled with the at rest measurements, and then go the the junk yard. But again, you really won't know what the spring rates on the donnor vehicle will be or how they will perform.



WRM
__________________
'92 YJ, 4.0, 5sp, 8.8 w/ 4.56's locked F&R, Teralow 4-1, HD SYE, BDS 5" SUA lifted on 35 MTR's. PSE front trail cage kit, 1ton TRE flip, 1"shackles, 1"BL, 1" MM. <><

Quote:
Originally Posted by 80 CHOPPER View Post
Knowledge is a tool, without knowledge, you are just a tool.
RockWoRM is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 12:54 PM   #8
moonshinefuel
Registered User
1995 YJ Wrangler

Join Date: Feb 2009
Location: Los Angeles. California. United States.
Posts: 4,911
Quote:
Originally Posted by Mudtracker View Post
Is this documented somewhere? I used the energy suspension bushings from Q-tec and they seem to work just fine. I've only had them on for a few weeks though.
Good info there, I remember I tried bushings other than emu and they did not fit properly. Good to know others do work. The problem is no, not much I know of is really documented on this subject. Thanks for the info.
moonshinefuel is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 01:29 PM   #9
Mudtracker
Registered User
1987 YJ Wrangler

Join Date: Jun 2009
Location: Ma
Posts: 51
Quote:
Originally Posted by moonshinefuel View Post
Good info there, I remember I tried bushings other than emu and they did not fit properly. Good to know others do work. The problem is no, not much I know of is really documented on this subject. Thanks for the info.
Yea when I was researching I couldnt find a whole lot of info on bushings. The thing that confused me the most was the directions that came with the Energy Suspension bushings say "Most spring eyes have an outer metal shell. Some shackles are this way as well. The outer shell must be removed."

But if you remove that the bushing would have about a 1/4" of space all around it. So I skipped that part.
Mudtracker is offline   Reply With Quote Quick reply to this message
Unread 04-05-2010, 01:41 PM   #10
Mudtracker
Registered User
1987 YJ Wrangler

Join Date: Jun 2009
Location: Ma
Posts: 51
Quote:
Originally Posted by Bridges31 View Post
Just looking for some advice here. First wheeling trip of the season left me with no jeep as I ended up hitting a rock or something with my shackle, causing the driver's side leaf spring to break in half. The mud was good though and I ended up not being able to see out of my windows when I was done

All four leaf springs on the jeep are old anyways. They are all straight with no bend left to them at all. Unfortunately, money is a little tight right now and I can't buy a lift kit so I just have to buy the springs.

My question is, what does everyone think about these? They seem like a decent price Old Man Emu CS014F - Old Man Emu 2.5" Front Stock-Heavy Load Leaf Spring for 87-95 Jeep® Wrangler YJ - Quadratec

Also, since im trying to save money, how lop-sided will my jeep look if I replace just the front two springs for now (the back one's are worn out with no bend)? Thanks.

I should add, everything is pretty much stock on the jeep with the exception of a little bit longer shackles and 31" tires.

Thanks!
I put 4 of those springs on my Jeep, another thing I couldnt find info about was if that would work or not. So far so good, the only thing I've noticed is that most rear spring packs have 5 leafs and these have 4. Not sure if that might make them more prone to sagging in the future?

Mudtracker is offline   Reply With Quote Quick reply to this message
Unread 04-07-2010, 04:54 PM   #11
YJ-Jer
Registered User
1994 YJ Wrangler

Join Date: Jul 2008
Location: Forsyth County, GA
Posts: 278
the BDS 2" kit is the same spring, front and rear. 4 leaf I believe.
__________________
-Jerry

Quote:
Originally Posted by unknown
"You know you drive a YJ when you run over a shadow and feel the steering wheel jerk."
Quote:
Originally Posted by Opihi59 View Post
3 Things to know about the forum: Always PB blaster, Always check the FAQ, Always do a search, and if none of that works, ask Mean Max.
YJ-Jer is offline   Reply With Quote Quick reply to this message
Unread 04-13-2010, 09:15 AM   #12
Bridges31
Registered User
1987 YJ Wrangler

Join Date: Jan 2009
Location: NH
Posts: 50
A follow up question to my OP..

I'm still price shopping. I came across an ad on craigslist for a full set of Rough Country 4" leafs for $200.00

The ad states they have approx. 5,000miles on them and that he took them out to switch back to stock springs for a SOA conversion (he stated that the 4" springs were too tall for his liking when going to SOA).

Would this be worth a shot? What other parts would I need if I were to put 4" leafs all around. I'm guess that I would need a brake line relocation bracket. Are the additional parts I would need be something I could pick up at a local auto parts store?

Sorry for all of these questions.. I've never delt with leaf springs/lifts before and I don't want to get screwed here lol

Thanks for the help
Bridges31 is offline   Reply With Quote Quick reply to this message
Unread 04-13-2010, 09:26 AM   #13
Mike
oooh you almost had it

Mike's Avatar

Join Date: Oct 2006
Location: va beach, va
Posts: 1,116
yep, brake lines would have to be addressed, as well as shocks, u-bolts (you would want new ones) usually a pitman arm and a transfer case drop or slip yoke eliminator/driveshaft combo. basically all the stuff that comes in a good lift kit. if you where closer i'd hook you up with some stock springs if it would help out.
Mike is offline   Reply With Quote Quick reply to this message
Unread 04-13-2010, 09:27 AM   #14
Bridges31
Registered User
1987 YJ Wrangler

Join Date: Jan 2009
Location: NH
Posts: 50
Quote:
Originally Posted by Mudvain View Post
yep, brake lines would have to be addressed, as well as shocks, u-bolts (you would want new ones) usually a pitman arm and a transfer case drop or slip yoke eliminator/driveshaft combo. basically all the stuff that comes in a good lift kit. if you where closer i'd hook you up with some stock springs if it would help out.
Thanks for the offer. So do you think I'm better off just buying the entire kit at one time when I have the money?

Or should I buy these springs off Craigslist and buy the additional items seperatly?
Bridges31 is offline   Reply With Quote Quick reply to this message
Unread 04-13-2010, 09:43 AM   #15
Mike
oooh you almost had it

Mike's Avatar

Join Date: Oct 2006
Location: va beach, va
Posts: 1,116
well, starting from $200 (price of springs) and adding shocks and a steering stab thats about an additional $150 if you stick to RC's brand. the RC 4" kit complete is $449 before Ryan gives you a JF member discount and, your good to go warranty wise if you need replacement springs. either way, you could save money piecing the parts together doing a little searching or buying a complete kit, its just how much time you want to invest doing it i guess is what it comes down to. i think buying a complete kit might save some headaches in the end.
Mike is offline   Reply With Quote Quick reply to this message
