Basic Maintenance - NP231J transfer case oil change

Here is a quick write-up on performing a fluid change on your NP231J transfer case. It's quick & easy, and will go a long way toward keeping your Jeep running smoothly!


Use a 30MM socket to remove the FILL PLUG FIRST to make sure you can refill it afterward.


Now drain the fluid. You can use an old piece of cardboard to keep the fluid from filling your skid plate. I was using a shop lift at the time, so I elected to skip the cardboard (regretfully) this time.


Let it drain until it drips out in individual drops. Then reinstall the drain plug.


I use the spout top from an old gear lube bottle on the top of the ATF quart bottle to refill the T-case.


I also have a spiffy little screw on funnel that makes refilling the quart bottles easier!


Refill it until it comes out of the fill plug, this way you'll know it's full!


PLEASE BE RESPONSIBLE & recycle all old fluids!


Max

__________________
Click here to see all of my different albums on Photobucket.
Choose any album to see all of my pics!


Quote:
Originally Posted by UltimatE View Post
Max has a picture of every Jeep part ever made.
Quote:
Originally Posted by Benderff View Post
No one here knows what they are talking about. You should try Pirate 4x4 they will be happy to help you.

There is no situation that cannot be improved with a small but well-placed explosive.
Mean Max is offline   Reply With Quote Quick reply to this message
Unread 04-08-2010, 08:37 PM   #2
rustywrangler
Got my eye on you.....

rustywrangler's Avatar

Join Date: Apr 2005
Location: Syracuse, NY
Posts: 18,616
Only thing to add would be to sweep out around with your finger to the right in the drain hole. The magnet sits right there and you can see if there are shavings on it or not.
__________________

Congenital Heart Disease is a reality for me, BOTH of my children have it. Please read up and become aware for future generations

Lydia Ann-Acquired 08/05/05 Open Heart surgery 08/10/05
Jacob Patrick-Acquired 01/17/08 Open Heart surgery 02/15/08
rustywrangler is offline   Reply With Quote Quick reply to this message
Unread 04-08-2010, 08:43 PM   #3
linusb
Registered User
1994 YJ Wrangler

Join Date: Aug 2009
Location: Lexington,SC
Posts: 1,769
Thanks. This is on my to do list for the weekend!
__________________
1994 YJ Wrangler, 4.0, AX15, NP231, 35x12.50x15 BFG KM2s, 4" RC lift, 1" lift Boom Shackles, 1" BL, 4.10 gears, 8.8 LSD in rear and D30 Aussie Locker in front, on-board air conversion, Ramsey RE8000 winch.
linusb is offline   Reply With Quote Quick reply to this message
Unread 04-08-2010, 09:43 PM   #4
bigorangeyj
Registered User
2002 TJ Wrangler

Join Date: Sep 2009
Location: FT. BRAGG
Posts: 394
doing this in the morning thanks
bigorangeyj is offline   Reply With Quote Quick reply to this message
Unread 04-08-2010, 10:46 PM   #5
bigorangeyj
Registered User
2002 TJ Wrangler

Join Date: Sep 2009
Location: FT. BRAGG
Posts: 394
could you tell me how much fluid i should buy for my tranny
bigorangeyj is offline   Reply With Quote Quick reply to this message
Unread 04-08-2010, 11:57 PM   #6
minnbowhunter
Registered User
1994 YJ Wrangler

Join Date: Mar 2010
Location: Minn
Posts: 69
Quote:
Originally Posted by bigorangeyj View Post
could you tell me how much fluid i should buy for my tranny
Pick up 3 quarts, you won't use it all but you can use the leftovers to make your own penetrating oil
minnbowhunter is offline   Reply With Quote Quick reply to this message
Unread 06-01-2010, 04:54 PM   #7
vodadub
Registered User
1994 YJ Wrangler

Join Date: Oct 2009
Location: Puerto Rico
Posts: 51
DAMMIT!
... Those 30mm bolts WON'T come out!!!
... and the one to refill is starting to go round. >_<'
vodadub is offline   Reply With Quote Quick reply to this message
Unread 06-01-2010, 04:57 PM   #8
Mean Max
Don't poke the bear

Mean Max's Avatar
1991 YJ Wrangler

Join Date: Jul 2007
Location: Stuart, Florida
Posts: 13,682
Quote:
Originally Posted by vodadub View Post
DAMMIT!
... Those 30mm bolts WON'T come out!!!
... and the one to refill is starting to go round. >_<'
I used this.......


.....on this socket


.......to get one like that out of an NP249 the other day.

Max
__________________
Click here to see all of my different albums on Photobucket.
Choose any album to see all of my pics!


Quote:
Originally Posted by UltimatE View Post
Max has a picture of every Jeep part ever made.
Quote:
Originally Posted by Benderff View Post
No one here knows what they are talking about. You should try Pirate 4x4 they will be happy to help you.

There is no situation that cannot be improved with a small but well-placed explosive.
Mean Max is offline   Reply With Quote Quick reply to this message
Unread 06-02-2010, 09:34 AM   #9
vodadub
Registered User
1994 YJ Wrangler

Join Date: Oct 2009
Location: Puerto Rico
Posts: 51
Well ...
The bolt was starting to go round with this...


and this...



So tried with this...


and this...



Nothing was coming out of there so ...
Ended up using ALL of THESE...






And a little imagination...

FINALLY popp'd out
vodadub is offline   Reply With Quote Quick reply to this message
Unread 06-05-2010, 10:03 PM   #10
cubewhiz
Registered User
1995 YJ Wrangler

Join Date: Sep 2009
Location: Kearny, New Jersey
Posts: 1,089
I was able to get mine off with no problem using this:
__________________
95 YJ with V8 going in, BDS 3.5" lift with MORE 5/8" boomerangs
Toyo Open Country M/T 33x12.50R15 on Cragar Soft 8 15x8 wheels
[URL="http://www.jeepforum.com/forum/f12/bobs-build-thread-1081112/"]My Build Thread[/URL]
--------
My new Jeep: 95 ZJ with 4.0L I6 (auto trans)
cubewhiz is offline   Reply With Quote Quick reply to this message
Unread 06-05-2010, 10:29 PM   #11
imstillatwork
Registered User
1993 YJ Wrangler

Join Date: Aug 2009
Location: Oregon Coast, Oregon
Posts: 1,480
Drive up on ramps to drain as much as you can if yours is really old and nasty, then pour a 1/2 quart through.
imstillatwork is offline   Reply With Quote Quick reply to this message
Unread 07-16-2010, 07:39 PM   #12
Sleuthhound
Registered User
1991 YJ Wrangler

Join Date: Dec 2009
Location: Vancouver, BC
Posts: 280
Thanks Max!

Just did my rear T-case seal (what a pain), and had to put torch to my fill plug to get it to crack!!
Sleuthhound is offline   Reply With Quote Quick reply to this message
Unread 02-24-2011, 07:50 AM   #13
PaulEspo
Registered User
1995 YJ Wrangler

Join Date: Feb 2011
Location: Caldwell, Idaho
Posts: 42
I just bought my Wrangler and have the Haynes Manual. I’m trying to get this straight in my head. I have a 1995 YJ, 2.5, 5 speed manual trans. So the Manual Transmission takes SAE 75-90W GL-5 Gear Lubricant, Same as the Differential., BUT the Transfer Case takes Automatic Transmission Fluid. I though this was a misprint but you show Auto Trans. In the posting.

Can I use 75W-140 in the transmission and the differential as well for towing?
PaulEspo is offline   Reply With Quote Quick reply to this message
Unread 02-24-2011, 08:49 AM   #14
Sleuthhound
Registered User
1991 YJ Wrangler

Join Date: Dec 2009
Location: Vancouver, BC
Posts: 280
The AX-15 takes 10W30 oil (I can't comment and your AX-5, but I imagine it would be the same? I don't know anything about putting gear lube into a tranny, is that what the book calls for?) T-case takes ATF, Diffs take gear lube. Engine takes 10W30 of course. :P
Sleuthhound is offline   Reply With Quote Quick reply to this message
Unread 02-24-2011, 02:42 PM   #15
GJeepFan
Registered User
1995 YJ Wrangler

Join Date: Dec 2010
Location: Southern, PA
Posts: 157
Quote:
Originally Posted by PaulEspo View Post
I just bought my Wrangler and have the Haynes Manual. Iím trying to get this straight in my head. I have a 1995 YJ, 2.5, 5 speed manual trans. So the Manual Transmission takes SAE 75-90W GL-5 Gear Lubricant, Same as the Differential., BUT the Transfer Case takes Automatic Transmission Fluid. I though this was a misprint but you show Auto Trans. In the posting.

Can I use 75W-140 in the transmission and the differential as well for towing?
DO NOT use 75-90W GL-5 gear lube in the transmission. The GL-5 has additives that are BAD for the syncro's. The oil spec for our AX-5' and the AX-15's is 10-30 MOTOR OIL. This was confirmed by Chrysler! (see other threads out there about this). I put Mobil 1 10-30 "high mileage" in my AX-5 recently, haven't driven it much yet, but from what I hear it's like "butter" with the 10-30 in it.

The Front and rear Diffs take GL-5 rated GEAR LUBE, 75-90 weight, I used the Wal-mart brand "Synthetic blend" in mine, seems like decent stuff.

The Transfer case does take ATF!

Good luck, hope this helps!
