When do I need an XJ steering box brace? How large size tires before needing brace?

At what point does an XJ need, or benefit from, a steering box brace?

Is a brace needed for 30 X 9.5 R15 tires?

For 31 X 10.5 R15 tires?

What brands of steering box brace do you recommend?


Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
Sponsored Links
Advertisement

post #2 of 19 Old 04-18-2013, 07:31 AM
K-R
Registered User
1998 XJ Cherokee

Join Date: Nov 2010
Location: Coon Creek (near Big Ugly)
Posts: 455
i used a c-rok brace.


'bout all I know... minin' coal.
K-R is offline
post #3 of 19 Old 04-18-2013, 11:24 AM
haloperformance
Registered User
1991 XJ Cherokee

Join Date: Oct 2012
Location: Rockaway
Posts: 154
Garage
I have the same brace. I put mine on when i made the jump from 31s to 35s. Is there any play where the box is mounted now? And stress cracks or anything that is making you concerned?

91 XJ: 35"s, 4:56s 5"LA lift 3"stretch, locked, skids, cage, high steer, spray paint.
98 XJ: Stock
haloperformance is offline
post #4 of 19 Old 04-18-2013, 11:33 AM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
I read somewhere that it's a good idea to have a steering box brace on an XJ if tires are 31" or larger.

Does that sound correct?

Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
post #5 of 19 Old 04-18-2013, 11:35 AM
dcorn
Registered User
1998 XJ Cherokee

Join Date: Aug 2007
Posts: 4,291
Just grab one whenever you can afford it. Or get a beefy front bumper that comes with frame plates anyway.

I was ok on 32's, but cracked my frame by the steering box right after I switched to 35s.

I think the braces that connect the steering box to the other side of the frame are better than just plating around the bolts. Add a trackbar brace that does the same thing.

2014 Jeep Grand Cherokee Summit
dcorn is offline
post #6 of 19 Old 04-18-2013, 12:22 PM
Timo_90xj
Web Wheeler

Timo_90xj's Avatar
1998 ZJ

Join Date: Mar 2006
Location: Helsinki, Finland - on the European side of the Atlantic
Posts: 7,593
People have cracked the steering box area with stock lift and tires. I'd recommend a steering box brace if you wheel your XJ. As mentioned above, the ones that use crush sleeves between the inner and outer plates are better. But just having plates on both sides will help a lot.

It's not a bad idea to use a trackbar brace too if you're running larger tires or use heavy pedal. I had a couple frame cracks on the front of my XJ, I wheeled it for two years on 35s and long arms, had a steering box brace and a sturdy winch bumper from day one.

1998 Grand Cherokee 5.9 LX daily driver, 1.75" BB, 32" KM2s, HPD30 Eaton e-locker/D44a stock LSD, 4.56 gears, custom- fabbed tube bumpers and tube fenders,...

http://www.jeepforum.com/forum/f13/d...s-etc-1222317/


1990 XJ Limited (4-door), 4.0 I6, AW4, NP242, ***rolled and totalled @ 165k miles***

***Under construction***
1990 XJ (4-door), 4.0 I6, AW4, NP242, PBR 42" tires, Unimog 404 portal axles, 110" WB, full cage + uniframe completely rebuilt, front 3-link + panhard / double triangulated 4-link rear,... ***SOLD***
Timo_90xj is online now
post #7 of 19 Old 04-18-2013, 02:21 PM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
Would a Detours Backbone bumper system with steering box brace be adequate steering box protection wheeling with 31" tires?

http://www.detoursusa.com/xjbackbone.php

http://www.detoursusa.com/images/xjbackbone03.jpg

Not necessarily set on getting it, but considering it.

Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
post #8 of 19 Old 04-18-2013, 02:22 PM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
Does that plate one or both sides? Does it have crush sleeves in middle?

Quote:
Originally Posted by K-R View Post
i used a c-rok brace.


Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
post #9 of 19 Old 04-18-2013, 02:24 PM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
What are good brands that have inner and outer plates with a crush sleeve in between? I want to stick with stock bumper, unless I get a Detours Backbone (which is still stock bumper looking).

Quote:
Originally Posted by Timo_90xj View Post
People have cracked the steering box area with stock lift and tires. I'd recommend a steering box brace if you wheel your XJ. As mentioned above, the ones that use crush sleeves between the inner and outer plates are better. But just having plates on both sides will help a lot.

It's not a bad idea to use a trackbar brace too if you're running larger tires or use heavy pedal. I had a couple frame cracks on the front of my XJ, I wheeled it for two years on 35s and long arms, had a steering box brace and a sturdy winch bumper from day one.

Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
post #10 of 19 Old 04-18-2013, 04:03 PM
1990JEEPXJ
Registered User

1990JEEPXJ's Avatar
1990 XJ Cherokee

Join Date: Aug 2006
Location: San Diego, CA
Posts: 7,153
Quote:
Originally Posted by Charley3
Does that plate one or both sides? Does it have crush sleeves in middle?
That is c-rok. And yes it plates the outside and comes with a new steel piece to mount the steering box to. And also crush sleeves.

Completely stock, and keeping it that way...

My POS
Quote:
Originally Posted by Joe Dillard View Post
Yea, and I thought it was one of the 11 Commandments:
11) Thou shalt love, cherish, and honor till death, thine square headlights above all other earthy things sayith the Lord.
1990JEEPXJ is offline
post #11 of 19 Old 04-18-2013, 05:05 PM
superogar5000
Registered User
2000 XJ Cherokee

Join Date: Aug 2012
Location: Newville
Posts: 6
I got a question I bought a inner brace from jcr and it didn't come with crush sleeves I haven't installed it yet do I need them? If so where can I find them (like local auto parts store or online) and what length and diameter?
superogar5000 is offline
post #12 of 19 Old 04-18-2013, 07:14 PM
dav5942
Member

dav5942's Avatar
1998 XJ Cherokee

Join Date: Aug 2008
Location: Stuart, Florida
Posts: 224
Quote:
Originally Posted by Charley3 View Post
Would a Detours Backbone bumper system with steering box brace be adequate steering box protection wheeling with 31" tires?

http://www.detoursusa.com/xjbackbone.php

http://www.detoursusa.com/images/xjbackbone03.jpg

Not necessarily set on getting it, but considering it.
With 31s four years, no brace, no problem.

With 33s two years with Detours Backbone-no problem.


Rubicon-a point of which any action taken commits the person taking it to a further course of action that cannot be avoided!
dav5942 is offline
post #13 of 19 Old 04-18-2013, 10:49 PM
ltrail
Registered User
1984 XJ Cherokee

Join Date: Sep 2010
Location: mesa
Posts: 1,458
Id have to agree with Timo90xj, if you wheel it, you brace it. I bought mine all stock with 4cyl. after 2 yrs of 4" lift/32's/lockers, my junk is all twisted in front and I wished I had plated the frame also. Now im building a box tube frame and cutting the old one off. Not an easy weekend project at all. Just brace as you go for peace of mind. You'll appreciate it in the end.

If your asking if you need something for extra strength, you probably do, within reason.

84 xj 350tbi, sm465, 203/205, 60/70. links and other junk.
what size sawzall blades does it take to fit 40's?
ltrail is offline
post #14 of 19 Old 04-19-2013, 12:01 AM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
Quote:
Originally Posted by ltrail View Post
If your asking if you need something for extra strength, you probably do, within reason.
Ya, I agree with you. In a prior XJ (96 XJ) I broke a stock rear differential running stock 225/75R15 AT tires doing some unintensional rock crawling. I got in to a situation that was more than I expected. Like that movie "Caught up", I got caught up and literally couldn't back out.

Currently, on a 99 XJ, I recently got 30 x 9.5 R15 Grabber AT2 (new version) and the run 0.3" to 0.5" taller than other brands of 30 x 9.5 R15 AT, and 0.5" to 0.75" wider. They look like a 10.25" wide tire to my eye.

I can feel the steering hesitating and straining while turning in to, or out of, parking lots, and when parking, and when hitting bumps on rural roads, and driving on a rough logging road that is almost off roading. All that in 2wd and I can feel the steering straining.

Warning: I often edit my posts a few times to get them complete, or to correct errors.
Charley3 is offline
post #15 of 19 Old 04-19-2013, 01:03 AM Thread Starter
Charley3
Web Wheeler
1999 XJ Cherokee

Join Date: Mar 2013
Posts: 5,538
I want to go to the C-Rok steering brace website and learn more about it, and probably buy it.

But Google didn't tell me a Web address.

What is the Web address for C-Rok manufacturer and seller? Where can I buy one?
