new to the jeep world. enigine pull question

Ive got a 2000 Cherokee 4x4 4.0L. I'm removing the motor to replace it due to piston problem and want advice on the best way to yank this thing. I'm down to the long block everything else is off, now i've her conflicting stories: 1) yank out attached to tranny and 2) disco from tranny then pull motor. Whats the easiest but also safest way. I've pulled a bunch of chevys but never a jeep just curious.

jcwc54 is offline   Reply With Quote Quick reply to this message
Unread 01-05-2012, 11:45 PM   #2
altrocker1
Registered User
1998 XJ Cherokee

Join Date: Jun 2008
Location: Jersey City, nj
Posts: 442
you can pull it without the tranny connected...pulls out easier, but there is a bolt or two that is a pain on top of the tranny...if you pull it all out together, they you have to disconnect linkage, cables etc
altrocker1 is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 05:26 AM   #3
cruiser54
Web Wheeler

cruiser54's Avatar
1990 MJ Comanche

Join Date: Oct 2009
Location: Prescott, Arizona
Posts: 10,320
Pull just the engine. Support the front of the trans with a floor jack. Remove the top two bell housing to engine bolts before loosening or removing any of the others.
cruiser54 is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 05:32 AM   #4
FairlanePhil
Registered User
2000 XJ Cherokee

Join Date: Feb 2010
Location: Toledo Ohio
Posts: 1,558
My vote

__________________
Patriot Blue 2000 XJ. SOLD
Wife has an 01 stocker
FairlanePhil is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 06:27 AM   #5
automan2164
Registered User
1986 MJ Comanche

Join Date: Dec 2009
Location: Harvard, IL
Posts: 200
I usually pull the whole thing, trans and all. But that's just me. I remove as little as possible, pull the front clip, and slide that monster out. I like it a lot better tearing everything apart on a stand or the floor rather than in the Jeep.

Rob
__________________
'86 MJ 2.1L 4x4 MT LWB - Factory Diesel
'87 MJ 4.0L 4x2 AT LWB - Metric Ton
'97 XJ 4.0L 4x4 AT Country
automan2164 is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 10:03 AM   #6
jcwc54
Registered User
2000 FSJ Cherokee

Join Date: Jan 2012
Location: walnut creek, ca
Posts: 3
thanks guys i appreciate it and am sure I'll have more questions along the way.
jcwc54 is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 11:32 AM   #7
Diamond-x
Registered User
1991 XJ Cherokee

Join Date: Aug 2008
Location: Socal
Posts: 1,195
Do you need to work on the trans? If not, just pull the long block.
Diamond-x is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 12:38 PM   #8
xj4thewin
Registered User
1992 XJ Cherokee

Join Date: Mar 2011
Location: denver, colorado
Posts: 73
Pull the engine by itself, I rebuilt mine this last summer, there's two bolts on the top of the bell housing like cruiser said, theirs a pain but less of a pain then removing the block with tranny to me.

__________________
92 XJ

My XJ Build
http://www.jeepforum.com/forum/f11/xj4tw-92-build-up-1182746/
xj4thewin is offline   Reply With Quote Quick reply to this message
Unread 01-06-2012, 02:44 PM   #9
Diamond-x
Registered User
1991 XJ Cherokee

Join Date: Aug 2008
Location: Socal
Posts: 1,195
If you remove the motor mounts and then lower the engine slightly, you can reach the top two trans bolts.
Diamond-x is offline   Reply With Quote Quick reply to this message
Unread 01-08-2012, 07:51 PM   #10
jcwc54
Registered User
2000 FSJ Cherokee

Join Date: Jan 2012
Location: walnut creek, ca
Posts: 3
got my block out and apart found blown up piston skirt in cylinder 3. Is this a common failure point? Also I will be rebuilding the motor seeing the only damage was to the piston itself and the motor had 170K on it made it seem like the best option. I have heard something about a particular head gasket to use on the rebuild, Anyone else hear this and what is it that is best to use? Also when I pull the distributor out of the block how do I ensure I get it back in for timing considerations?
jcwc54 is offline   Reply With Quote Quick reply to this message
Unread 01-09-2012, 09:46 AM   #11
xj4thewin
Registered User
1992 XJ Cherokee

Join Date: Mar 2011
Location: denver, colorado
Posts: 73
When I rebuilt my motor this is what I referenced for the timing.

http://www.angelfire.com/my/fan/dist_index.html

Its actually really hard to not get the timing right with the 4.0l
__________________
92 XJ

My XJ Build
http://www.jeepforum.com/forum/f11/xj4tw-92-build-up-1182746/
xj4thewin is offline   Reply With Quote Quick reply to this message
